Panasonic NV-DS30A - Page 88

DIODES
Ref. No. Part No. Part Name & Description Remarks
D6502 SLR7123A50AB LIGHT EMITTING DIODE *NOTE
RESISTORS
Ref. No. Part No. Part Name & Description Remarks
R6501 ERJ3GEYJ560V MGF CHIP 1/16W 56 *NOTE
R6502 ERJ8GEYJ270V MGF CHIP 1/8W 27 *NOTE
R6503 D0HB122ZA002 MGF CHIP 1/16W 1.2K *NOTE
R6504 D0HB562ZA002 MGF CHIP 1/16W 5.6K *NOTE
R6505 D0HB122ZA002 MGF CHIP 1/16W 1.2K *NOTE
R6506 ERJ3GEYJ821V MGF CHIP 1/16W 820 *NOTE
CAPACITORS
Ref. No. Part No. Part Name & Description Remarks
C6501 ECST0JY106 TANTALUM CHIP 6.3V 10UF *NOTE
C6502 ECJ1VF1C104Z C CHIP 16V 0.1UF *NOTE
C6503 ECJ1VB1C104K C CHIP 16V 0.1UF *NOTE
PIN HEADERS
Ref. No. Part No. Part Name & Description Remarks
P6501 K1KA03A00304 CONNECTOR 3P *NOTE
FPC CONNECTRO
Ref. No. Part No. Part Name & Description Remarks
FP6501 K1MN10A00030 CONNECTOR 10P *NOTE
MISCELLANEOUS
Ref. No. Part No. Part Name & Description Remarks
U6501 B3RAD0000039 INFRARED RECEOVER *NOTE
13.3.4. ELECTRONIC VIEWFINDER BACK LIGHT C.B.A.
TRANSISTORS
Ref. No. Part No. Part Name & Description Remarks
Q951 2SD2216J0L TRANSISTOR SI NPN CHIP *NOTE
Q951 2SC4617-R TRANSISTOR SI NPN CHIP *NOTE
DIODES
Ref. No. Part No. Part Name & Description Remarks
D951 B3AFB0000016 LIGHT EMITTING DIODE *NOTE
RESISTORS
88
