Ref. No. Part No. Part Name & Description Remarks
R951 ERJ3GEY0R00V MGF CHIP 1/16W 0 *NOTE
R952 ERJ3GEY0R00V MGF CHIP 1/16W 0 *NOTE
R953 ERJ3GEYJ223V MGF CHIP 1/16W 22K *NOTE
R954 ERJ3GEYJ103V MGF CHIP 1/16W 10K *NOTE
R955 ERJ3GEYJ101V MGF CHIP 1/16W 100 *NOTE
R956 ERJ3GEYJ102V MGF CHIP 1/16W 1K *NOTE
R957 ERJ3GEY0R00V MGF CHIP 1/16W 0 *NOTE
CAPACITORS
Ref. No. Part No. Part Name & Description Remarks
C952 ECJ1VF1C104Z C CHIP 16V 0.1UF *NOTE
C953 ECJ1VF1C104Z C CHIP 16V 0.1UF *NOTE
C954 ECJ1VF1C104Z C CHIP 16V 0.1UF *NOTE
C955 ECJ1VF1C104Z C CHIP 16V 0.1UF *NOTE
FPC CONNECTOR
Ref. No. Part No. Part Name & Description Remarks
FP951 K1MN19B00052 CONNECTOR 19P *NOTE
FP952 K1MN20B00085 CONNECTOR 20P *NOTE
13.3.5. LIQUID CRYSTAL DISPLAY C.B.A.
INTEGRATED CIRCUITS
Ref. No. Part No. Part Name & Description Remarks
IC8001 AN2540FHQ-V IC, LINEAR
TRANSISTORS
