Panasonic PT-DW530U

PICTURE menu
44
- ENGLISH
Settings
Press <ENTER> button.7 )
The [WHITE BALANCE] screen will be
z
displayed.
Press ▲▼ to select [WHITE 8 )
BALANCE HIGH] or [WHITE
BALANCE LOW].
Press <ENTER> button.9 )
The [WHITE BALANCE HIGH (or LOW)]
z
screen will be displayed.
Press ▲▼ to select [RED], [GREEN] 10 )
or [BLUE].
Press ◄► to adjust the level.11 )
Item Operation Adjustment
Adjustment
range
RED
Press ►. Deepens red.
Maximum
value
HIGH : 255
LOW : 127
Minimum
value
HIGH : 0
LOW :
-
127
Default
HIGH : 255
LOW : 0
Press ◄. Weakens red.
GREEN
Press ►. Deepens green.
Press ◄. Weakens green.
BLUE
Press ►. Deepens blue.
Press ◄. Weakens blue.
Note
All colors will not be displayed properly unless adequate
z
adjustment is made. If the adjustment does not look
suitable, you can press <DEFAULT> button to return the
setting for the selected item only to the factory default
setting.
The [COLOR TEMPERATURE] cannot be adjusted
z
for the internal test pattern (
Æ
page 70). Be sure to
project the input signal when adjusting the [COLOR
TEMPERATURE].
Changing the name of [USER]
J
Select [USER] in step 3).1.
Press <ENTER> button.2.
The [COLOR TEMPERATURE] screen will be
z
displayed.
Press ▲▼ to select [COLOR 3.
TEMPERATURE NAME CHANGE].
Press <ENTER> button.4.
The [COLOR TEMPERATURE NAME
z
CHANGE] screen will be displayed.
Press ▲▼◄► to select characters 5 )
and press <ENTER> button to input
them.
Press ▲▼◄► to select [OK], and 6.
press <ENTER> button.
The color temperature setting name is changed.
z
WHITE GAIN
Adjusts the brightness of a white image.
Press▲▼to select [WHITE GAIN]1 )
Press ◄► or <ENTER> button.2 )
The [WHITE GAIN] control screen is displayed.
z
Press ◄► to adjust the brightness 3 )
level.
Operation Adjustment
Adjustment
range
Press ►
button.
Increases the image
brightness.
Maximum
value: 10
Press ◄
button.
Displays the natural
image.
Minimum
value: 0
COLOR TEMPERATURE NAME CHANGE
