Panasonic PT-MZ11K

Chapter 2 Getting Started — Setting up
42 - ENGLISH
r When the screen aspect ratio is 16:9
(Unit: m)
Lens type Zoom Lens
Projection lens Model No. ET‑EMU100
ET‑EMS650/
ET‑EMS600
ET‑EMW200 ET‑EMW300 ET‑EMW400 ET‑EMW500
Throw ratio
*1
0.330‑0.353:1 1.35‑2.10:1 0.480‑0.550:1 0.550‑0.690:1 0.690‑0.950:1 0.950‑1.36:1
Projected image size Projection distance (L)
Diagonal (SD)
Height
(SH)
Width
(SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
2.03 (80") 0.996 1.771 ― ― 2.37 3.75 0.83 0.97 0.96 1.22 1.20 1.69 1.66 2.41
2.29 (90") 1.121 1.992 ― ― 2.67 4.22 0.94 1.10 1.08 1.38 1.36 1.90 1.87 2.71
2.54 (100") 1.245 2.214 0.72 0.77 2.97 4.69 1.06 1.22 1.21 1.53 1.52 2.12 2.09 3.02
3.05 (120") 1.494 2.657 0.87 0.93 3.57 5.64 1.27 1.48 1.46 1.85 1.83 2.56 2.51 3.63
3.81 (150") 1.868 3.321 1.09 1.18 4.48 7.06 1.60 1.87 1.83 2.32 2.30 3.21 3.15 4.56
5.08 (200") 2.491 4.428 1.47 1.58 5.99 9.43 2.14 2.50 2.45 3.11 3.08 4.29 4.22 6.09
6.35 (250") 3.113 5.535 1.84 1.98 7.49 11.79 2.69 3.14 3.07 3.90 3.87 5.37 5.29 7.63
7.62 (300") 3.736 6.641 2.22 2.39 9.00 14.16 3.24 3.78 3.70 4.68 4.65 6.46 6.36 9.16
8.89 (350") 4.358 7.748 2.59 2.79 10.51 16.53 3.78 4.42 4.32 5.47 5.43 7.54 7.43 10.70
10.16 (400") 4.981 8.855 2.97 3.20 12.02 18.89 4.33 5.06 4.94 6.26 6.22 8.62 8.50 12.23
12.70 (500") 6.226 11.069 ― ― 15.04 23.63 5.42 6.33 6.19 7.83 7.78 10.79 10.63 15.30
15.24 (600") 7.472 13.283 ― ― 18.06 28.36 6.52 7.61 7.43 9.41 9.40 12.96 12.77 18.37
*1 The throw ratio is based on the value during projection with the projected image size of 2.54 m (100").
(Unit: m)
Lens type Zoom Lens Height position (H)
Projection lens Model No.
ET‑EMT750/
ET‑EMT700
ET‑EMT850/
ET‑EMT800
*2
ET‑EMS650/
ET‑EMS600/
ET‑EMW400/
ET‑EMW500/
ET‑EMT750/
ET‑EMT700/
ET‑EMT850/
ET‑EMT800
*2
ET‑EMU100 ET‑EMW200 ET‑EMW300
Throw ratio
*1
2.10‑4.15:1 4.12‑7.40:1
Projected image size Projection distance (L)
Diagonal (SD)
Height
(SH)
Width
(SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
2.03 (80") 0.996 1.771 3.65 7.35 7.31 13.23
- 0.17 - 1.16 ― 0.06 - 0.94
-0.06 - 1.05
2.29 (90") 1.121 1.992 4.12 8.28 8.18 14.84
- 0.19 - 1.31 ― 0.06 - 1.06
-0.06 - 1.18
2.54 (100") 1.245 2.214 4.60 9.20 9.10 16.40
- 0.21 - 1.45 - 0.07 - 0.90 0.07 - 1.18
-0.07 - 1.31
3.05 (120") 1.494 2.657 5.53 11.08 10.80 19.69
- 0.25 - 1.74 - 0.08 - 1.08 0.08 - 1.41
-0.08 - 1.58
3.81 (150") 1.868 3.321 6.94 13.87 13.42 24.54
- 0.31 - 2.18 - 0.10 - 1.35 0.10 - 1.76
-0.10 - 1.97
5.08 (200") 2.491 4.428 9.29 18.53 17.78 32.62
- 0.42 - 2.91 - 0.14 - 1.80 0.14 - 2.35
-0.14 - 2.63
6.35 (250") 3.113 5.535 11.64 23.19 22.15 40.70
- 0.52 - 3.63 - 0.17 - 2.25 0.17 - 2.94
-0.17 - 3.29
7.62 (300") 3.736 6.641 13.99 27.85 26.51 48.78
- 0.62 - 4.36 - 0.21 - 2.70 0.21 - 3.53
-0.21 - 3.94
8.89 (350") 4.358 7.748 16.35 32.51 30.88 56.86
- 0.73 - 5.08 - 0.24 - 3.15 0.24 - 4.12
-0.24 - 4.60
10.16 (400") 4.981 8.855 18.70 37.17 35.24 64.94
- 0.83 - 5.81 - 0.28 - 3.60 0.28 - 4.70
-0.28 - 5.26
12.70 (500") 6.226 11.069 23.40 46.49 43.97 81.11
- 1.04 - 7.26 ― 0.35 - 5.88
-0.35 - 6.57
15.24 (600") 7.472 13.283 28.10 55.80 52.70 97.27
- 1.25 - 8.72 ― 0.42 - 7.06
-0.42 - 7.89
*1 The throw ratio is based on the value during projection with the projected image size of 2.54 m (100").
*2 ET-EMT800 cannot be used with the projected image size of
15.24 (600").
