Panasonic PT-RZ12K

Chapter 6 Appendix — Technical information
ENGLISH - 211
Control device password
To initialize your password, consult your distributor.
Upgrade Kit
If the optional Upgrade Kit (Model No.: ET-UK20) is applied, the following functions are extended.
Function Standard status When the Upgrade Kit is applied
Adjustment range of
[VERTICAL KEYSTONE]
Maximum of ±40°
*1
Maximum of ±45°
*1
Adjustment range of
[HORIZONTAL KEYSTONE]
Maximum of ±15°
*1
Maximum of ±40°
*1
Adjustment range of
[CURVED]
Vertical arc, Maximum ±50
*1
Horizontal arc, Maximum ±50
*1
Vertical arc, Maximum ±100
*1
Horizontal arc, Maximum ±100
*1
[CUSTOM MASKING] Cannot be used. The image is masked in optional form.
[PC CORRECTION] of
[UNIFORMITY]
Cannot be used. Correct the brightness and color unevenness of the
entire screen.
*1 The adjustment range of the menu. Refer to “[GEOMETRY] projection range” (x page 39) for the possible projection range.
