Panasonic PT-RZ12K

Chapter 6 Appendix — Technical information
208 - ENGLISH
Compatible signal
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
Format
Plug and play
*1
Horizontal
(kHz)
Vertical
(Hz)
RGB2
DVI-D
HDMI
EDID1 EDID2 EDID3
1920 x 1200
1 920 x 1 200 61.8 49.9 158.3 R/D/H ― ― ― ― ―
1 920 x 1 200
*8
74.0 60.0 154.0 R/D/H
l
―
l l
*10
l
*10
1 920 x 1 200
*9
74.6 59.9 193.3 R ― ― ― ― ―
*1 Signals with a l in the Plug and play columns are signals described in EDID (extended display identication data) of the projector. If a signal has no
l in the Plug and play columns but has an entry in the Format column, it can be input. For signals without a l in the Plug and play columns, there
are instances when resolution cannot be selected on the computer even though the projector supports them.
*2 Only for single link connection
*3 Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
*4 When a 1125 (1035)/60i signal was input, it is displayed as a 1125 (1080)/60i signal.
*5 Dual link HD-SDI is supported.
*6 Dual link 3G-SDI is supported.
*7 Image is displayed as 3D image in the frame sequential format when [3D INPUT FORMAT] is set to [AUTO]. To display images in 2D, set [3D
INPUT FORMAT] to [NATIVE].
*8 VESA CVT-RB (Reduced Blanking)-compliant
*9 Samples the pixels in the image processing circuit and projects the image.
*10 Only for PT-RZ12K
Note
f A signal with a different resolution is converted to the number of display dots. The number of display dots is as follows.
g PT-RZ12K: 1 920 x 1 200
g PT-RS11K: 1 400 x 1 050
f The “i” at the end of the resolution indicates an interlaced signal.
f When interlaced signals are connected, ickering may occur on the projected image.
f DIGITAL LINK input compatible signal is the same as HDMI input compatible signal.
List of simultaneous input 2D compatible signals
The following table species the simultaneous input (2D) compatible video signals that the projector can project.
2D compatible signal
Resolution
(Dots)
Scanning freq.
Dot clock freq.
(MHz)
HDMI/DVI SDI1/SDI2
Horizontal
(kHz)
Vertical
(Hz)
1080/50p 1 920 x 1 080 56.3 50.0 148.5
l l
1080/60p 1 920 x 1 080 67.5 60.0 148.5
l l
1366 x 768
1 366 x 768 39.6 49.9 69.0
l
―
1 366 x 768 47.7 59.8 85.5
l
―
1400 x 1050
1 400 x 1 050 54.1 50.0 99.9
l
―
1 400 x 1 050 65.3 60.0 121.8
l
―
1920 x 1080
1 920 x 1 080 55.6 49.9 141.5
l
―
1 920 x 1 080 66.6 59.9 138.5
l
―
1920 x 1200
1 920 x 1 200 61.8 49.9 158.3
l
―
1 920 x 1 200 74.0 60.0 154.0
l
―
