Panasonic PT-RZ12K

Chapter 4 Settings — [PICTURE] menu
88 - ENGLISH
Setting item Details
[LIGHTS OUT TIMER]
(Time setting until the light turns
off)
[DISABLE] Does not turn off the light source.
[0.0s] - [10.0s]
Turns off the light source when the brightness level of the video
signal being input goes under the value set in [LIGHTS OUT
SIGNAL LEVEL].
Select an item from [0.0s] - [4.0s], [5.0s], [7.0s], or [10.0s]. [0.0s] -
[4.0s] can be selected in increments of 0.5.
[LIGHTS OUT SIGNAL
LEVEL]
(Setting of the brightness level
of the signal to turn off the light)
[0%] - [5%]
Set the level of the brightness of the video signal to turn off the light
source with [LIGHTS OUT TIMER].
Can be set in increments of 1 %. (Factory setting: 0 %)
[MANUAL INTENSITY]
(Manual light source
adjsutment)
[0] - [255]
The larger the value, the stronger the correction.
Can be set in increments of 1. (Factory setting: 255)
[DYNAMIC GAMMA]
(Adjustment of signal
compensation)
[OFF] Does not compensate the signal.
[1] Slightly compensates the signal.
[2] Moderately compensates the signal.
[3] Strongly compensates the signal.
Note
f [LIGHTS OUT SIGNAL LEVEL] cannot be set when [LIGHTS OUT TIMER] is set to [DISABLE].
f When [LIGHTS OUT TIMER] is set to anything other than [DISABLE], the following are the conditions to turn the light source back on again
from the state that the light source has turned off by this function.
g When the brightness level of the video signal being input has exceeded the value set in [LIGHTS OUT SIGNAL LEVEL]
g When the input signal is gone
g When on-screen display such as menu screen (OSD) or input guide, a test pattern, or a warning message is displayed
g When the operating environment temperature is around 0 °C (32 °F) and the light source is forced to turn on due to warm-up
f When [LIGHTS OUT TIMER] is set to anything other than [DISABLE], it will take approximately 0.5 seconds to turn the light source back on
again from the state that the light source has turned off by this function.
f When the image of analog signal is projected, the image may be affected by the signal noise while the brightness level of the video signal is
detected. In this case, even when the brightness level of the image falls below the value set in [LIGHTS OUT SIGNAL LEVEL], it is judged
that the brightness level is not below the value as a signal.
Analog signal refers to Y/C signal, YC
B
C
R
/YP
B
P
R
signal, and analog RGB signal.
f When [DYNAMIC GAMMA] is set to [3], the contrast will be maximized.
f The brightness control function and the dynamic contrast function will operate simultaneously, but the dynamic contrast function will not
operate while measuring the brightness and the color.
[SYSTEM SELECTOR]
The projector will automatically detect the input signal, but you can set the system method manually when an
unstable signal is input. Set the system method matching the input signal.
1) Press as to select [SYSTEM SELECTOR].
2) Press the <ENTER> button.
3) Press as to select a system format.
f Select the system format using asqw when the signal is input to the <SDI IN 1>/<SDI IN 2> terminals.
f Available system formats vary depending on the input signal.
Terminal System format
<R/P
R
/VIDEO> terminal, <G/
Y>/<B/P
B
/C> terminal
Select [AUTO], [NTSC], [NTSC4.43], [PAL], [PAL-M], [PAL-N], [SECAM], or [PAL60].
Set it to [AUTO] normally. (Setting [AUTO] will automatically select [NTSC], [NTSC4.43], [PAL],
[PAL-M], [PAL-N], [SECAM], or [PAL60].)
Switch the setting to the signal method for the TV used.
<RGB 1 IN> terminal, <RGB 2
IN> terminal
480i, 576i, or 576p signal Select [RGB] or [YC
B
C
R
].
VGA60 or 480p signal Select [VGA60], [480p YC
B
C
R
], or [480p RGB].
Other movie-based signals Select [RGB] or [YP
B
P
R
].
<DVI-D IN> terminal
480i, 576i, 480p, or 576p
signal
Select [RGB] or [YC
B
C
R
].
Other movie-based signals Select [RGB] or [YP
B
P
R
].
<HDMI IN> terminal, <DIGITAL
LINK/LAN> terminal
480i, 576i, 480p, or 576p
signal
Select [AUTO], [RGB], or [YC
B
C
R
].
Other movie-based signals Select [AUTO], [RGB], or [YP
B
P
R
].
