42 - ENGLISH
Note
f It is recommended that the images are projected continuously for at least 30 minutes before the focus is adjusted.
f If you adjust the focus, you may need to adjust the size of the image by changing the distance between the screen and the projector.
f When the focus is adjusted, the projection screen size also changes slightly. Depending on the image projection situation, repeat Steps 1)
and 2) to adjust to the best projection condition.
f Adjust from the [POSITION] menu → [SCREEN ADJUSTMENT] (x page 58) when the projected image is distorted.
Adjusting adjustable feet
By pressing the adjustable feet lock with your nger, the adjustable feet lock is released and becomes free. It will
be locked when you release the nger. Lift the front side of the projector while pressing the adjustable feet lock
with your nger, and release your nger until the projection position is aligned.
For slight adjustment, rotate the adjustable feet.
Rotate the adjustable foot to extend it as shown in the gure, and rotate it in the opposite direction to contract it.
Maximum adjustable range
Adjustable feet : 37 mm (1-15/32")
Feet lock
Feet lock
Attention
f Heated air comes out of the exhaust vent while the lamp is lit. Do not touch the exhaust vent directly when you adjust the adjustable feet.
f Adjust from the [POSITION] menu → [SCREEN ADJUSTMENT] (x page 58) when the projected image is distorted.
Chapter 3 Basic Operations - Projecting
