Panasonic PT-VW345NZ

Standard setting-up position
unit : mm (inch)
NOTE:
Illustrations show the projector
installed using optional ceiling mount
bracket ET-PKV100H and bracket
assembly ET-PKV101B.
This illustration is not drawn to scale.
Caution:
• All construction work should be done by a qualified technician.
• When mounting to the ceiling, use the special mounting bracket. To prevent the projector from swaying or drop-
ping, attach the wire that is included with the projector between the mounting bracket and the ceiling.
0.76 m
1.02 m
1.27 m
1.52 m
1.78 m
2.03 m
2.29 m
2.54 m
3.05 m
3.81 m
5.08 m
6.35 m
7.62 m
0.7
1.0
1.3
1.5
1.8
2.0
2.3
2.5
3.1
3.8
5.1
6.4
7.7
1.2
1.6
2.0
2.5
2.9
3.3
3.7
4.1
4.9
6.2
8.2
10.3
12.4
0.01
0.01
0.01
0.02
0.02
0.02
0.02
0.03
0.03
0.04
0.05
0.07
0.08
30˝
40˝
50˝
60˝
70˝
80˝
90˝
100˝
120˝
150˝
200˝
250˝
300˝
/
/
/
/
/
/
/
/
/
/
/
/
/
(2.3)
(3.3)
(4.3)
(4.9)
(5.9)
(6.6)
(7.5)
(8.2)
(10.2)
(12.5)
(16.7)
(21.0)
(25.3)
(3.9)
(5.2)
(6.6)
(8.2)
(9.5)
(10.8)
(12.1)
(13.5)
(16.1)
(20.3)
(26.9)
(33.8)
(40.7)
(0.03)
(0.03)
(0.03)
(0.07)
(0.07)
(0.07)
(0.07)
(0.10)
(0.10)
(0.13)
(0.16)
(0.23)
(0.26)
Projection size
[diagonal]
Projection distance [L]
Min [wide] Max [telephoto]
Height from the edge of screen
to center of lens [H]
Projection distance for 16:10 aspect ratio screen
unit: meters (feet)
NOTE:
.scitsiretcarahcsnelmoozehtnognidnepedylthgilsseirav)neercsotecnatsid(LrofeulavehT•
• At the shortest projection distance, the zoom lens characteristics may cause slight image distortion.
63 (2-15/32)
100
(3-15/16)
200
(7-7/8)
70
140
(5-1/2)
70 (2-3/4)
(2-3/4)
100
(3-15/16)
153.9
(5-1/16)
125.5
(4-15/16)
Lower edge of projected image
Upper edge of projected image
Projected image
L
L
HH
ø38
(1-1/2)
840–1,410
(33-1/16–55-1/2)
Adjustable in
30-mm
(1-3/16-inch) step.
Projected image
L
PT-VW345NZ
LCD Projectors
As of October 2013 6/14
SFL13M006
