33
ENGLISH
VQT3T18
33
Specifications
Power
Battery DC 1.5 V
(1 AAA LR03 battery)
Audio
Sampling frequency
(The information in brackets
is the sound quality)
44.1 kHz [HQ 128 kbps]
16 kHz [LP 32 kbps]
Recording format MP3
Frequency response
(-10 dB, during
recording/playback)
(The information in brackets
is the sound quality)
300 Hz to 21,000 Hz
[HQ 128 kbps]
300 Hz to 6,700 Hz
[LP 32 kbps]
Built-in microphone S/N ratio
41 dB (HQ) Filter (JIS A)
USB USB 2.0 (Hi-Speed)
DC 5 V / 150 mA
Audio
output
Headphone/earphone
jack (Monaural)
ø 3.5 mm, 16 Ω,
Max. 6.4 mW
Speaker output ø 20 mm, 8 Ω,
80 mW (RMS)
Audio
input
External microphone
jack (Monaural)
ø 3.5 mm, 1.6 mV
plug in power
Max. dimensions 37.5 mm x 107.8 mm x 15.7 mm
(W x H x D)
Cabinet
dimensions
37 mm x 107.5 mm x 15 mm
(W x H x D)
Weight Approx. 50 g (with battery)
Approx. 39 g (without battery)
Operational
temperature
0 °C to 40 °C
Operational
humidity
20% to 80% RH
(no condensation)
Recording capacity
(memory capacity)
2 GB
∗
1
∗
1 Usable capacity will be less.
Battery life
(This may be shorter depending on the operating
conditions.)
Sound quality
Recording
∗
2
Playback
∗
3
HQ Approx. 23 hours Approx. 13 hours
LP Approx. 34 hours Approx. 15 hours
Using Panasonic alkaline AAA/LR03 battery
∗
2 When not monitoring recording and recording indicator OFF
∗
3 When audio is output from the speaker with the volume set
to 10
Estimated possible recording time
(This may be shorter depending on the operating
conditions.)
Sound quality
Recording time Bit rate
HQ Approx. 34 hours 128 kbps
LP Approx. 136 hours 32 kbps
● These specifications are subject to change without
notice.
