Notes:
S6801: RIGHT (
/ ) switch.
S6802: UP (
) switch.
S6803: LEFT (
/ ) switch.
S6804: DOWN (
) switch.
S6805: FM/AM/MUSIC P. switch.
S6806: STOP/DEMO (-DEMO/
) switch.
S6807: OPTION (
/ ) switch.
S6808: OPEN/CLOSE (
) switch.
S6809: USB (
/ ) switch.
S6810: D.BASS switch.
S6811: CD_PLAY (
/ ) switch.
S6812: REC_USB switch.
S6813: POWER (
) switch.
S7201: REST switch.
S7202: CD OPEN switch.
VR6801: VR VOLUME jog.
VR6881: VR BASS jog.
VR6882: VR TREBLE jog.
• Importance safety notice :
Components identified by
mark have special
characteristics import ant for safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufacturer´s specified parts shown in the parts list.
• Resistor
Unit of resistance is OHM [Ω] (K=1,000).
• Capacitor
Unit of resistance is µF, unless otherwise noted. F=Farad,
pF=Pico-Farad
• Coil
Unit of inductance is H, unless otherwise noted.
• *
For Indication only.
• Voltage and Signal lines:
: +B Signal line
: -B Signal line
: CD-DA signal line
: CD signal line
: FM/AM signal line
: MAIN signal line
: MUSIC PORT / D-DOCK signal line
: USB signal line
