Notes:
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 L6FALEFH0030 FAN UNIT [M]
2 REEX0840 17P FFC CABLE (PANEL A-MAIN) [M]
3 REEX0841 20P FFC CABLE (JUPITER-MAIN) [M]
4 REEX0842 22P FFC CABLE (MECHANISM-
MAIN)
[M]
5 REEX0843 14P FFC CABLE (D-PORT-MAIN) [M]
6 REEX0876 6P FFC CABLE (JUPITER-PANEL
A)
[M]
7 REXX0660 5P WIRE (JUPITER-USB) [M]
8 REXX0658 8P WIRE (POWER-TRANS) [M]
9 REZX0018-1 GROUND WIRE [M]
10 RFKGAPMX3GNS FRONT PANEL ASS’Y [M]
11 RGKX0450-S CD LID [M]
12 RGKX0456-S VOLUME KNOB ORNAMENT [M]
13 RGKX0460A-S USB LID [M]
14 RGLX0162-Q POWER LIGHTNING PIECE [M]
15 RGLX0163-Q RIPPING BUTTON LIGHT PIECE [M]
16 RGWV0046-S VOLUME KNOB UNIT [M]
17 RGUX0750-S CD EJECT BUTTON [M]
18 RGUX0754-S RIPPING BUTTON [M]
19 RGUX0758A-S POWER BUTTON [M]
20 RGWV0040-S2 BASS TREBLE [M]
21 RKMX0142-S TOP CABINET [M]
22 RFKHAPMX3GNS REAR CABINET ASS’Y [M]
23 RMBX0073 CD LID SPRING [M]
24 RMBX0082 USB LID SPRING [M]
25 RXXX0106 HEATSINK UNIT [M]
26 RXXX0108 HEATSINK UNIT [M]
27 RSCX0178-1 REAR SHIELD [M]
28 RSCX0186-1 SD SHIELD (TOP) [M]
29 RSCX0187 SD SHIELD (BOTTOM) [M]
30 RWJ1104100SX 4P WIRE (PANEL A-TRANS) [M]
31 RWJ1104150SX 4P FLAT WIRE (PANEL A-MAIN) [M]
32 RWJ1803110SS 3P JUMPER WIRE [M]
33 RWJ1806080SS 6P WIRE (PANEL A-PANEL B) [M]
34 XTB3+8JFJ SCREW [M]
35 RHD26046-L SCREW [M]
36 RHD30007-1SJ SCREW [M]
Ref.
No.
Part No. Part Name & Description Remarks
37 RHDV30006 SCREW [M]
38 RHDX03001 SCREW [M]
40 RKAX0040 LEG FELT [M]
41 RMCX0035 HEATSINK CLIP A [M]
42 RMGX0033 CUSHION RUBBER [M]
43 RMKX0146-1 BOTTOM CHASSIS [M]
44 RMKX0147 INNER CHASSIS [M]
45 RMNV0062 FL HOLDER [M]
46 RMNX0266-S CD MECHA BRACKET [M]
47 RMY0355 HEATSINK UNIT [M]
48 XTB3+10JFJ SCREW [M]
49 XTWS3+6TFJ SCREW [M]
50 RMBX0083 GROUND SPRING [M]
TRAVERSE DECK
301 RAEX0190Z-V TRAVERSE UNIT [M]
(RTL)
310 XTN2+6GFJ SCREW [M]
PACKING MATERIALS
P1 RPGX1837 PACKING CASE [M]
P2 RPNX0519-1 POLYFOAM [M]
P3 RPHV0001-1 MIRAMAT SHEET [M]
ACCESSORIES
A1 N2QAYB000257 REMOTE CONTROL [M]
A1-1 RKK-HTR0051K R/C BATTERY COVER [M]
A2 K2CJ2DA00008 AC CORD [M]
A3 RQTX0166-B O/I BOOK (En) [M]
A4 RSA0007-L1 FM INDOOR ANTENNA [M]
A5 N1DAAAA00001 AM LOOP ANTENNA [M]
PRINTED CIRCUIT BOARDS
PCB1 REPX0633A TRANSFORMER P.C.B [M]
(RTL)
21 Replacement Parts List
• Important safety notice:
Components identified by
mark have special charac teristics important for safety.
Furthermore, special parts which have purposes of fire-retardent (resistors), high-quality sound (capacitors), low noise
(resistors), etc are used.
When replacing any of these components, be sure to use only manufacturer’s specified parts shown in the parts list.
• The parenthesized indications in the Remarks columns specify the areas or colour. (Refer to the cover page for area or colour)
Parts without these indications can be used for all areas.
• Warning: This product uses a laser diode. Refer to “Precaution of Laser Diode” .
• Capacitor values are in microfarads (µF) unless specified otherwise, P= Pico-farads (pF), F= Farads.
• Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM).
• The marking (RTL) indicates that the Retention Time is limited for this items. After the discontinuation of this assembly in
production, the item will continue to be available for a specific period of time. The retention period of a availability is dependent
on the type of assembly, and in accordance with the laws governing part and product retention. After the end of this period, the
assembly will no longer be available.
• [M] Indicates in the Remarks columns indicates parts supplied by PAVCSG.
• Reference for O/I book languages are as follows:
Ar: Arabic Du: Dutch It: Italian Sp: Spanish
Cf: Canadian French En: English Ko: Korean Sw: Swedish
Cz: Czech Fr: French Po: Polish Co: Traditional Chinese
Da: Danish Ge: German Ru: Russian Cn: Simplified Chinese
Pe: Persian Ur: Ukraine Pr: Portuguese
93
