Panasonic SA-PMX3GN - Page 94

Ref.
No.
Part No. Part Name & Description Remarks
PCB2 REPX0633A POWER P.C.B [M]
(RTL)
PCB3 REPX0646C MAIN P.C.B [M]
(RTL)
PCB4 REPX0646C USB CONNECTOR P.C.B [M]
(RTL)
PCB5 REPX0646C PANEL B P.C.B [M]
(RTL)
PCB6 REPX0646C PANEL A P.C.B [M]
(RTL)
PCB7 REPX0651B D-PORT P.C.B [M]
(RTL)
PCB8 REPX0636A CD SERVO P.C.B [M]
(RTL)
PCB9 REPX0660D JUPITER P.C.B [M]
(RTL)
INTEGRATED CIRCUITS
IC502 C0DBZYE00002 IC SWITCH [M]
IC551 C0FBAK000026 IC ADC [M]
IC552 C0FBBY000027 IC DAC [M]
IC701 RFKW0660D IC FLASH ROM [M]
IC751 C3ABPG000160 IC EEPROM [M]
IC801 MN2WS0042AA IC SD MODULE LSI [M]
IC802 C0DBZYY00293 IC LDO VOLTAGE REGULATOR [M]
IC2801 RFKWPMX3GN IC MICRO-PROCESSOR [M]
IC2802 C1AB00002885 IC AUDIO SOUND PROCESSOR [M]
IC2803 C0CBAHE00002 IC VOLTAGE REGULATOR [M]
IC2804 C0DAEJG00001 IC LDO VOLTAGE REGULATOR [M]
IC2809 C0DBCYY00005 IC +3.3V VOLTAGE REGULATOR [M]
IC2810 C0CBCBC00090 IC +3.3V VOLTAGE REGULATOR [M]
IC2811 C0AABB000125 IC HEAD-AMP [M]
IC2812 C0CBABE00056 IC VOLTAGE REGULATOR [M]
IC5000 C1BA00000487 IC DIGITAL POWER-AMP [M]
IC6801 C0HBB0000057 IC FL DISPLAY DRIVER [M]
IC7001 MN6627954MA IC SERVO PROCESSOR / DSP /
DIGITAL FILTER D/A CONVERTER
[M]
IC7002 BA5948FPE2 IC 4 CH DRIVE [M]
TRANSISTORS
Q2500 B1GBCFLL0037 TRANSISTOR [M]
Q2501 B1ADCE000012 TRANSISTOR [M]
Q2502 B1ABEB000002 TRANSISTOR [M]
Q2503 B1GBCFGN0016 TRANSISTOR [M]
Q2504 B1GBCFGN0016 TRANSISTOR [M]
Q2505 B1GBCFGN0016 TRANSISTOR [M]
Q2506 B1GBCFGN0016 TRANSISTOR [M]
Q2508 B1GDCFJJ0047 TRANSISTOR [M]
Q2510 B1HBECA00004 TRANSISTOR [M]
Q2600 B1AAJC000019 TRANSISTOR [M]
Q2601 B1AAJC000019 TRANSISTOR [M]
Q2800 B1ABCF000174 TRANSISTOR [M]
Q2801 B1ABCF000174 TRANSISTOR [M]
Q2802 B1ACKD000006 TRANSISTOR [M]
Q2803 B1ABCF000174 TRANSISTOR [M]
Q2900 B1ADCE000012 TRANSISTOR [M]
Q2901 B1GBCFJJ0051 TRANSISTOR [M]
Q5100 B1BACG000023 TRANSISTOR [M]
Q5101 B1ABCF000176 TRANSISTOR [M]
Q5102 B1ABCF000176 TRANSISTOR [M]
Q5103 B1DEGM000026 TRANSISTOR [M]
Q5104 B1GACFGA0002 TRANSISTOR [M]
Q5105 B1DEGM000026 TRANSISTOR [M]
Q5106 2SB0709AHL TRANSISTOR [M]
Q5107 B1ABCF000176 TRANSISTOR [M]
Q5108 B1GBCFJJ0051 TRANSISTOR [M]
Q5109 B1GBCFJJ0051 TRANSISTOR [M]
Q5501 B1GDCFGG0026 TRANSISTOR [M]
Q5503 B1ABGC000005 TRANSISTOR [M]
Q5601 B1ABCF000176 TRANSISTOR [M]
Q5603 B1ADCE000012 TRANSISTOR [M]
Q5604 B1ABCF000176 TRANSISTOR [M]
Q5910 B1ABCF000176 TRANSISTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
Q5911 B1ABCF000176 TRANSISTOR [M]
Q5912 B1GBCFJJ0051 TRANSISTOR [M]
Q5921 B1BCCG000002 TRANSISTOR [M]
Q5922 B1ABCF000176 TRANSISTOR [M]
Q5927 B1BCCG000002 TRANSISTOR [M]
Q5950 B1ABCF000176 TRANSISTOR [M]
Q5970 B1GBCFJJ0051 TRANSISTOR [M]
Q5971 B1BABG000007 TRANSISTOR [M]
Q5972 B1GBCFGN0016 TRANSISTOR [M]
Q5990 B1ACKD000006 TRANSISTOR [M]
Q6801 B1ABCF000176 TRANSISTOR [M]
Q7601 B1ADCF000001 TRANSISTOR [M]
QR2501 B1GDCFGG0026 TRANSISTOR [M]
DIODES
D801 MA27D2900L DIODE [M]
D802 B0JCMD000022 DIODE [M]
D2500 MA2J11100L DIODE [M]
D2501 MA2J11100L DIODE [M]
D2502 MA2J11100L DIODE [M]
D2503 MA2J11100L DIODE [M]
D2702 MA2J11100L DIODE [M]
D2703 MA2J11100L DIODE [M]
D2705 MA2J11100L DIODE [M]
D2706 MA2J11100L DIODE [M]
D2707 MA2J11100L DIODE [M]
D2800 B0ADCJ000020 DIODE [M]
D2900 B0EAKM000117 DIODE [M]
D5022 MA2J11100L DIODE [M]
D5101 MA2J11100L DIODE [M]
D5103 MAZ81200ML DIODE [M]
D5104 MAZ80560ML DIODE [M]
D5105 MAZ81200ML DIODE [M]
D5106 B0EAKM000117 DIODE [M]
D5107 MAZ80560ML DIODE [M]
D5108 B0EAKM000117 DIODE [M]
D5109 MAZ81500ML DIODE [M]
D5110 B0EAKM000117 DIODE [M]
D5111 MAZ80510ML DIODE [M]
D5112 B0EAKM000117 DIODE [M]
D5503 MAZ80510ML DIODE [M]
D5901 MA2J11100L DIODE [M]
D5902 MA2J11100L DIODE [M]
D5911 B0EAMM000038 DIODE [M]
D5912 B0EAMM000038 DIODE [M]
D5913 B0EAMM000038 DIODE [M]
D5914 B0EAMM000038 DIODE [M]
D5920 B0EAKM000117 DIODE [M]
D5921 B0EAKM000117 DIODE [M]
D5922 B0EAKM000117 DIODE [M]
D5923 B0EAKM000117 DIODE [M]
D5926 MAZ80750ML DIODE [M]
D5927 MA2J11100L DIODE [M]
D5928 B0EAKM000117 DIODE [M]
D5929 B0EAKM000117 DIODE [M]
D5930 B0EAKM000117 DIODE [M]
D5931 B0EAKM000117 DIODE [M]
D5950 MA2J11100L DIODE [M]
D5951 MAZ80510ML DIODE [M]
D5952 B0EAKM000117 DIODE [M]
D5960 B0BC026A0007 DIODE [M]
D5961 B0EAKM000117 DIODE [M]
D5962 B0EAKM000117 DIODE [M]
D5970 MA2J11100L DIODE [M]
D5971 MAZ80620ML DIODE [M]
D5972 B0EAKM000117 DIODE [M]
D5973 B0EAKM000117 DIODE [M]
D5974 B0EAKM000117 DIODE [M]
D5975 B0EAKM000117 DIODE [M]
D5976 MA2J11100L DIODE [M]
D6801 B3AAA0000487 DIODE [M]
D6802 MAZ80820ML DIODE [M]
94
SA-PMX3GN
