Ref.
No.
Part No. Part Name & Description Remarks
D6803 MAZ80680ML DIODE [M]
D6804 B3AAA0000487 DIODE [M]
D7650 MAZ80560ML DIODE [M]
DZ2600 MAZ81200ML DIODE [M]
DZ2601 MAZ81200ML DIODE [M]
VARIABLE RESISTORS
VR6801 EVEJ1LF3024B VR VOLUME [M]
VR6881 K9AA012Y0002 VR BASS [M]
VR6882 K9AA012Y0002 VR TREBLE [M]
SWITCHES
S6801 EVQ21405RJ SW RIGHT [M]
S6802 EVQ21405RJ SW UP [M]
S6803 EVQ21405RJ SW LEFT [M]
S6804 EVQ21405RJ SW DOWN [M]
S6805 EVQ21405RJ SW FM/AM/AUX [M]
S6806 EVQ21405RJ SW STOP/DEMO [M]
S6807 EVQ21405RJ SW OPTION [M]
S6808 EVQ21405RJ SW OPEN/CLOSE [M]
S6809 EVQ21405RJ SW USB [M]
S6810 EVQ21405RJ SW DBB [M]
S6811 EVQ21405RJ SW CD_PLAY [M]
S6812 EVQ21405RJ SW REC_USB [M]
S6813 EVQ21405RJ SW POWER [M]
S7201 K0L1BA000133 SW REST [M]
S7202 K0L1BA000133 SW CD OPEN [M]
CONNECTORS
CN502 K1MN06AA0076 6P CONNECTOR [M]
CN503 K1KA05BA0014 5P CONNECTOR (USB) [M]
CN601 K1MY20BA0046 20P CONNECTOR [M]
CN602 K1MY10AA0021 10P CONNECTOR [M]
CN2801 K1MN14AA0003 14P CONNECTOR [M]
CN2802 K1MN22AA0004 22P CONNECTOR [M]
CN2803 K1MY17AA0124 17P FFC CONNECTOR [M]
CN2804 K1MN20AA0004 20P CONNECTOR [M]
CN2805 K1KB08B00041 8P CONNECTOR [M]
CN2806 K1KA02AA0186 2P CONNECTOR (FAN) [M]
CN2807 K1KC05A00001 5P CONNECTOR [M]
CN2808 K1KB05B00022 5P CONNECTOR [M]
CN2809 K1MP04A00003 4P CONNECTOR [M]
CN2810 K1KB13B00017 13P CONNECTOR [M]
CN4000 K1MN14BA0147 14P CONNECTOR [M]
CN4100 K1FY124DA001 CONNECTOR [M]
CN4801 K1KA13AA0031 13P CONNECTOR [M]
CN4802 K1KA13AA0031 13P CONNECTOR [M]
CN5100 K1KA05AA0031 5P CONNECTOR [M]
CN5101 K1KA08AA0031 8P CONNECTOR [M]
CN5104 K1KA08AA0319 8P CONNECTOR [M]
CN5900 K1KB13B00017 13P CONNECTOR [M]
CN5904 K1MP04A00003 4P CONNECTOR [M]
CN6801 K1MN17B00032 17P CONNECTOR [M]
CN6802 K1MN06BA0004 6P CONNECTOR [M]
CN7001 K1MN16B00154 16P FFC CONNECTOR [M]
CN7002 K1MN22BA0005 22P CONNECTOR [M]
CN9001 K1FY104B0011 USB CONNECTOR [M]
CN9002 K1KA05BA0014 5P CONNECTOR [M]
COILS AND TRANSFORMERS
L551 G1C100KA0101 INDUCTOR [M]
L552 G1C100KA0101 INDUCTOR [M]
L553 G1C100KA0101 INDUCTOR [M]
L804 G1C100KA0101 INDUCTOR [M]
L805 G1C100KA0101 INDUCTOR [M]
L2900 J0JKB0000020 INDUCTOR [M]
L2901 G0C100JA0055 INDUCTOR [M]
L2902 G0C100JA0055 INDUCTOR [M]
L2903 G0C100JA0055 INDUCTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
L2905 G0C100JA0055 INDUCTOR [M]
L2910 J0JBC0000019 INDUCTOR [M]
L2911 J0JBC0000019 INDUCTOR [M]
L2912 J0JBC0000019 INDUCTOR [M]
L5000 G0ZZ00002657 COIL [M]
L5001 G0B9R5K00004 LINE FILTER [M]
L5002 G0B9R5K00003 LINE FILTER [M]
L5500 J0JKB0000020 INDUCTOR [M]
L5501 J0JKB0000020 INDUCTOR [M]
L5970 ELF15N035AN LINE FILTER [M]
L6801 J0JBC0000019 INDUCTOR [M]
L6802 G0C3R3JA0052 INDUCTOR [M]
L6803 J0JBC0000019 INDUCTOR [M]
L6804 J0JBC0000019 INDUCTOR [M]
L6805 J0JBC0000019 INDUCTOR [M]
L6806 G0C101JA0052 INDUCTOR [M]
L6807 J0JBC0000019 INDUCTOR [M]
L6808 J0JBC0000019 INDUCTOR [M]
L6809 G0C100JA0055 INDUCTOR [M]
L6810 G0C100JA0055 INDUCTOR [M]
LB503 J0JBC0000118 INDUCTOR [M]
LB504 J0JBC0000118 INDUCTOR [M]
LB601 J0JAC0000021 INDUCTOR [M]
LB602 J0JHC0000045 INDUCTOR [M]
LB603 J0JAC0000021 INDUCTOR [M]
LB605 J0JAC0000021 INDUCTOR [M]
LB614 J0JHC0000045 INDUCTOR [M]
LB615 J0JAC0000021 INDUCTOR [M]
LB616 J0JHC0000045 INDUCTOR [M]
LB618 J0JAC0000021 INDUCTOR [M]
LB619 J0JHC0000045 INDUCTOR [M]
LB620 J0JAC0000021 INDUCTOR [M]
LB621 J0JAC0000021 INDUCTOR [M]
LB622 J0JAC0000021 INDUCTOR [M]
LB623 J0JHC0000045 INDUCTOR [M]
LB624 J0JAC0000021 INDUCTOR [M]
LB625 J0JBC0000019 INDUCTOR [M]
LB626 J0JAC0000021 INDUCTOR [M]
LB628 J0JAC0000021 INDUCTOR [M]
LB629 J0JBC0000019 INDUCTOR [M]
LB630 J0JAC0000021 INDUCTOR [M]
LB801 J0JAC0000024 INDUCTOR [M]
LB802 J0JAC0000024 INDUCTOR [M]
TRANSFORMERS
T5900 G4CYAYY00174 TRANSFORMER [M]
T5901 G4CYAYY00137 TRANSFORMER [M]
COMPOMENT COMBINATION
Z2701 ENG06836QRF TUNER PACK [M]
Z5970 ERZVA5Z471 ZENER [M]
Z6801 B3RAD0000146 REMOTE CONTROL SENSOR [M]
ZJ4801 K4CZ01000027 TERMINAL [M]
ZJ5400 K4CZ01000027 TERMINAL [M]
ZJ5401 K4CZ01000027 TERMINAL [M]
OSCILLATOR
X801 H0J169500031 CRYSTAL OSCILLATOR [M]
X802 H0J120500057 CRYSTAL OSCILLATOR [M]
X2000 H2B100500007 CRYSTAL OSCILLATOR [M]
X2001 H0A327200111 CRYSTAL OSCILLATOR [M]
X7201 H0H169500013 CRYSTAL OSCILLATOR [M]
FL DISPLAY
FL6801 A2BB00000166 FL DISPLAY [M]
RELAY
RL5970 K6B1AEA00003 RELAY [M]
