Panasonic SA-VK81D - Page 142

Ref. No. Part No. Part Name & Description Remarks
S6820 EVQ21405R SW DISC 4 [M]
S6821 EVQ21405R SW DISC 3 [M]
S6822 EVQ21405R SW DISC 2 [M]
S6823 EVQ21405R SW DISC 1 [M]
S6824 EVQ21405R SW SOUND EQ [M]
S6825 EVQ21405R SW S.WOOFER [M]
S6826 EVQ21405R SW SOUND EQ [M]
CONNECTORS
CN1 K1MN14B00066 14P CONNECTOR [M]
CN950 RJT119W10V 10P CONNECTOR [M]
CN951 RJT119W07V 7P CONNECTOR [M]
CN953 RJT029W03VT 3P CONNECTOR [M]
CN971 K1MN10B00104 10P FFC CONNECTOR [M]
CN1001 K1MN14B00058 14P CONNECTOR [M]
CN2801 K1KB12B00036 12P CONNECTOR [M]
CN2802 K1KB12B00036 12P CONNECTOR [M]
CN2806 K1KA02A00008 2P CONNECTOR [M]
CN2808 K1KA10A00263 10P CONNECTOR [M]
CN2809 K1KA02A00375 2P CONNECTOR [M]
CN2810 K1MN14B00066 14P CONNECTOR [M]
CN2811 K1MN30A00046 30P FFC CONNECTOR [M]
CN2813 K1MN50A00008 50P CONNECTOR [M]
CN2814 RJT029W03VT 3P CONNECTOR [M]
CN2815 K1MN28A00016 28P FFC CONNECTOR [M]
CN2816 K1KA02A00375 2P FFC CONNECTOR [M]
CN5801 K1KA02A00375 2P CONNECTOR [M]
CN5802 K1KA02A00375 2P CONNECTOR [M]
CN5802 REXX0383 2P WIRE [M]
CN5806 K1KA07A00184 7P CONNECTOR [M]
CN5807 RJT119W08V CONNECTOR [M]
CN5808 K1KB12B00036 12P CONNECTOR [M]
CN5809 K1KB12B00036 12P CONNECTOR [M]
CN5810 RJT119W15V 15P WIRE HOLDER [M]
CN5811 RJT119W15V 15P WIRE HOLDER [M]
CN6800 K1KA11B00033 11P CONNECTOR [M]
CP5801 K1KA12A00184 12P CONNECTOR [M]
CP5802 K1KA12A00184 12P CONNECTOR [M]
CP5803 K1KA12A00184 12P CONNECTOR [M]
CP5804 K1KA12A00184 12P CONNECTOR [M]
CP6800 K1MN10B00104 10P FFC CONNECTOR [M]
CP6801 K1MN30A00046 30P FFC CONNECTOR [M]
CP6802 K1MN28A00016 28P FFC CONNECTOR [M]
CP6803 K1MN14A00049 14P FFC CONNECTOR [M]
CP6804 RJU071H11M 11P CONNECTOR [M]
CS1001 RJS1A6805-J 5P CONNECTOR [M]
CS1002 RJS1A6805-J 5P CONNECTOR [M]
FP8101 K1MN50B00031 50P CONNECTOR [M]
FP8271 K1MN15B00041 15P CONNECTOR [M]
FP8501 K1MN26B00094 26P CONNECTOR [M]
COILS & TRANSFORMERS
L500 G0B371HA0005 LINE FILTER [M]
L1001 G0C470JA0030 RF CHOKE COIL [M]
L1002 7L1A62N BIAS OSC COIL [M]
L2100 J0JBC0000041 CHIP INDUCTOR [M]
L2101 J0JBC0000041 CHIP INDUCTOR [M]
L2200 J0JBC0000041 CHIP INDUCTOR [M]
L2201 J0JBC0000041 CHIP INDUCTOR [M]
L2802 G0A101G00022 COIL [M]
L2805 G0A101G00022 COIL [M]
L2809 ELESN220JA COIL [M]
L2810 ELJFCR39KF CHIP INDUCTOR [M]
L2811 J0JCC0000120 CHIP INDUCTOR [M]
L2812 J0JCC0000120 CHIP INDUCTOR [M]
L2813 J0JCC0000120 CHIP INDUCTOR [M]
L2814 J0JCC0000120 CHIP INDUCTOR [M]
L2815 J0JCC0000120 CHIP INDUCTOR [M]
L2816 J0JCC0000120 CHIP INDUCTOR [M]
Ref. No. Part No. Part Name & Description Remarks
L2819 J0JBC0000019 CHIP INDUCTOR [M]
L2820 G0C221KA0007 COIL [M]
L2821 G0C100JA0030 INDUCTOR [M]
L6800 G0C3R3JA0030 COIL [M]
L6801 G0C101JA0030 INDUCTOR [M]
L6802 G0C101JA0030 INDUCTOR [M]
L6803 G0C101JA0030 INDUCTOR [M]
L6804 G0C100JA0030 INDUCTOR [M]
L6805 G0C100JA0030 INDUCTOR [M]
L6806 G0C3R3JA0030 COIL [M]
L6807 G0C100JA0030 INDUCTOR [M]
L6808 G0C100JA0030 INDUCTOR [M]
L6809 G0C100JA0030 INDUCTOR [M]
L6810 G0C101JA0030 INDUCTOR [M]
L8201 G1C100K00020 CHIP INDUCTOR [M]
L8202 J0JCC0000079 FILTER [M]
L8301 G1C100KA0055 CHIP INDUCTOR [M]
L8302 J0JCC0000079 FILTER [M]
L8420 G1C220KA0055 CHIP INDUCTOR [M]
L8550 G1C100KA0055 CHIP INDUCTOR [M]
T501 G4C8AHK00003 POWER TRANSFORMER [M]
T502 G4C2AAJ00005 BACK-UP TRANSFORMER [M]
COMPONENT COMBINATION
Z501 ERZV10V511CS ZENER [M]
Z971 RGSD12A1445T RADA RESISTOR [M]
Z6800 B3RAB0000025 REMOTE SENSOR [M]
BS6800 RMBX0032 GROUND SPRING [M]
RELAY
RL502 RSY0040M-0 PRIMARY RELAY [M]
OSCILLATORS
X6800 H2A100500006 RESONATOR [M]
X6801 H0A327200073 CRYSTAL OSCILLATOR [M]
X8621 H0J270500064 S/MOUNTING CRYSTAL [M]
DISPLAY TUBES
FL6800 A2BD00000092 FL DISPLAY [M]
FL8101 F1H0J1050022 1 6.3V [M]
FL8102 F1H0J1050022 1 6.3V [M]
FL8103 F1H0J1050022 1 6.3V [M]
FL8104 F1J1E1040022 0.1 25V [M]
FUSES
F1 K5D402BL0007 FUSE [M]
F2 K5D202BL0007 FUSE [M]
F3 K5D632BL0007 FUSE [M]
F4 K5D632BL0007 FUSE [M]
FUSE HOLDERS
FC1 EYF52BC FUSE HOLDER [M]
FC2 EYF52BC FUSE HOLDER [M]
FC3 EYF52BC FUSE HOLDER [M]
FC4 EYF52BC FUSE HOLDER [M]
FC5 EYF52BC FUSE HOLDER [M]
FC6 EYF52BC FUSE HOLDER [M]
FC7 EYF52BC FUSE HOLDER [M]
FC8 EYF52BC FUSE HOLDER [M]
FUSE PROTECTORS
FP5801 K5G402A00010 FUSE PROTECTOR [M]
FP5802 K5G102A00023 FUSE PROTECTOR [M]
HOLDERS
142
SA-VK81DGCS / SA-VK81DGCP
