18 Service Position
18.1. Checking Procedure
Note:
For the disassembling procedure, see Section 17.
18.2. Checking the Main P.C.B., Power P.C.B., Power Supply P.C.B., Power
Amp P.C.B., Transformer P.C.B., Voltage Selector P.C.B. and AC Inlet
P.C.B.
1. Remove Top Cabinet and Rear Panel.
2. Remove DVD Mechanism Unit.
3. Connect FFC board (CN2810 & CN2813) from DVD Mechanism Unit.
