Panasonic SA-VK81D - General Specifications

(3) DVD-Video
(4) DVD-R (DVD-Video compatible)
(5) CD-Audio (CD-DA)
(6) Video CD
(7) SVCD (Conforming to IEC62107)
(8) CD-R/CD-RW (CD-DA, Video CD, SVCD, MP3, WMA, JPEG
formatted disc)
(9) MP3/WMA*
· Compatible compression rate:
MP3: between 32 kbps and 320 kbps
WMA: between 48 kbps and 192 kbps
(10) JPEG*
· Exif Ver 2.1 JPEG Baseline files
· Picture resolution: between 320x240 and 6144x4096 pixels
(Sub sampling is 4:2:2 or 4:2:0)
(11) HighMAT Level 2 (Audio and Image)
· The total combined maximum number of recognizable audio and
picture contents and groups: 4000 audio and picture contents
and 400 groups.
Pick up
Wavelength (DVD/CD) 662 nm/785 nm
A
udio ouptut (Disc)
Number of channels 5.1ch(FL,FR,C,SL,SR,SW)
A
udio performance (measurement at: Line out terminal)
Frequency response
CD-Audio 4Hz-20kHz(+1,-2dB)
n VIDEO SECTION
Video system
Signal system PAL625/50, PAL525/60, NTSC
Composite video output
Output level 1Vp-p(75Ω)
Terminal Pin jack (1 system)
S VIDEO output
Y output level 1Vp-p(75Ω)
C output level 0.3 Vp-p (75Ω)(PAL)
0.286 Vp-p (75Ω)(NTSC)
Terminal S terminal (1 system)
Component video output (480P/480I)
Y output level 1Vp-p(75Ω)
1 Before Use
4
2 Before Repair and Adjustment
4
3 Protection Circuitry
4
4 Safety Precautions
4
4.1. General Guidelines
4
P
B
output level 0.7 Vp-p (75 Ω)
P
R
output level 0.7 Vp-p (75 Ω)
Terminal
Pin jack (Y: green, P
B
:blue,P
R
:red)(1system)
n GENERAL
Power supply
AC 110V/127V/220-230V/240V, 50/60Hz
Power consumption 275 W
Power consumption in standby mode:
1W
Dimensions (WxHxD) 250 x 330 x 372 mm
Mass 9.6 kg
Operating temperature range +5°Cto+35°C
Operating humidity range 5% to 90% RH (no condensation)
n SYSTEM
SC-VK81D(GCS) Music Center: SF-VK81D (GCS)
Front Speaker: SB-VK81D (GC)
Center Speaker: SB-PC81 (GC) x
1
Surround Speaker: SB-PS81 (GC)
x2
Subwoofer: SB-WVK81 (GC) x 1
SC-VK81D(GCP) Music Center: SF-VK81D (GCP)
Front Speaker: SB-VK81D (GC)
Center Speaker: SB-PC81 (GC) x
1
Surround Speaker: SB-PS81 (GC)
x2
Subwoofer: SB-WVK81 (GC) x 1
SF-VK81D GCSS consists of SA-VK81D GCS & SB-PT81GC-S
SB-PT81 GC-S consists of SB-PS81 (GC) x 2 & SB-PC81 (GC) x 1
SB-VK81D GCP-S consists of SB-PS81 (GC) x 2 & SB-PC81 (GC) x
1
Notes:
1. Specifications are subject to change without notice. Mass and
dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
5 Prevention of Electro Static Discharge (ESD) to
Electrostatically Sensitive (ES) Devices
5
6 Handling the Lead-free Solder
6
6.1. About lead free solder (PbF)
6
7 Cautions to be taken when handling Optical Pickup
7
7.1. Handling Optical Pickup
7
CONTENTS
Page Page
2
SA-VK81DGCS / SA-VK81DGCP
