* Transfer rates are theoretical values; however, actual
communication rate will vary according to communication
environment or connected equipment.
* This unit supports “HDAVI Control 5” function.
Surround speakers
[BTT775] SB-HS775
Type: 2 WAY 3 SPEAKER Bass-ref.
Woofer: 3.5 cm k 10 cm
CONE TYPEk 2
Tweeter: 2.5 cm SEMI-DOME TYPE
Impedance: 3 ≠
Output sound pressure: 78 dB/W (1 m)
Frequency range: 100 Hz to 30 kHz (j16 dB),
130 Hz to 25 kHz (j10 dB)
Dimensions (WkHkD): 255 mmk1024 mmk255 mm
Mass: Approx. 2.3 kg
[BTT770] [BTT370] [BTT270] SB-HS270
Type: 1 WAY 1 SPEAKER Bass-ref.
Full range: 6.5 cm CONE TYPE
Impedance: 3 ≠
Output sound pressure: 78 dB/W (1 m)
Frequency range: 105 Hz to 25 kHz (j16 dB),
130 Hz to 22 kHz (j10 dB)
Dimensions (WkHkD): 80 mmk117 mmk70.5 mm
Mass: Approx. 0.35 kg
Subwoofer
[BTT775] [BTT770] [BTT370] SB-HW370
Type:
1 WAY 1 SPEAKER Bass- ref.
Woofer: 16 cm CONE TYPE
Impedance: 3 ≠
Output sound pressure: 78 dB/W (1 m)
Frequency range: 30 Hz to 220 Hz (j16 dB),
35 Hz to 180 Hz (j10 dB)
Dimensions (WkHkD): 180 mmk408 mmk300 mm
Mass: Approx. 4.3 kg
[BTT270] SB-HW270
Type: 1 WAY 1 SPEAKER Bass- ref.
Woofer: 16 cm CONE TYPE
Impedance: 3 ≠
Output sound pressure: 78 dB/W (1 m)
Frequency range: 40 Hz to 220 Hz (j16 dB),
45 Hz to 180 Hz (j10 dB)
Dimensions (WkHkD): 145 mmk289.5 mmk258 mm
Mass: Approx. 3.0 kg
TERMINAL SECTION
USB:
(Front)
USB standard: USB 2.0 1 system
USB Port: DC OUT 5 V 500 mA MAX
(Rear)
[BTT775] [BTT770]
[BTT370]
USB Port for
Communication
Camera: USB 2.0 1 system
DC OUT 5 V 500 mA
[BTT270]
USB Port for Wi-Fi
READY: USB 2.0 1 system
DC OUT 5 V 500 mA
SD card slot: Connector: 1 system
Ethernet: 10BASE-T/100BASE-TX 1 system
[BTT775] [BTT770] [BTT370] WLAN
Antenna:
Tx 1, Rx 2
Standard Compliance:IEEE802.11n / IEEE802.11a /
IEEE802.11g / IEEE802.11b
Transmission system: MISO-OFDM system,
OFDM system, DSSS system
Transfer rate (Standard)*:
IEEE802.11n: Tx Max. 150 Mbps, Rx Max.
300 Mbps
IEEE802.11g /
IEEE802.11a: Max. 54 Mbps
IEEE802.11b: Max. 11 Mbps
Access Mode: Infrastructure mode
Security: WPA2-PSK (TKIP/AES)
WPA-PSK (TKIP/AES)
WEP (64 bit / 128 bit)
(This unit supports WPA and WPA2
encryption.)
Audio Input
AUX: k 1
Digital Audio Input
Optical: k 1
[BTT775]
[BTT770]
[BTT370] HDMI AV Input:
k 2
Sampling frequency: 32 kHz, 44.1 kHz, 48 kHz
Audio Format: PCM, Dolby Digital, DTS
VIDEO SECTION
Signal system: PAL/NTSC
Video output
Output level: 1.0 Vp-p (75 ≠)
Output connector: Pin jack (1 system)
HDMI AV output*
Output connector: Type A (19 pin)
[BTT775]
[BTT770] [BTT370]
HDMI AV Input*
Input connector: Type A (19 pin) 2 system
LASER Specification
Class 1 LASER Product
Wave length: 790 nm (CDs)/655 nm (DVDs)/
405 nm (BDs)
Laser power:
No hazardous radiation is
emitted with the safety protection
