Panasonic SC-HTB15 User Manual

Reference
29
VQT3R83
Specifications

1 Specifications are subject to change without notice.
2 Weight and dimensions are approximate.
3 Total harmonic distortion is measured by a digital spectrum
analyzer.
4 Total harmonic distortion is measured by using AES17 filter.
AMPLIFIER SECTION
RMS output power
10 % total harmonic distortion
Subwoofer ch 120 W per channel (100 Hz, 3 ≠ )
Front ch (L, R ch)
60 W per channel (1 kHz, 6 ≠)
Total RMS Dolby Digital mode power 240 W
TERMINAL SECTION
HDMI
This unit supports “HDAVI Control 5” function.
HDMI AV input (HDMI 1, HDMI 2) 2
Input connector Type A (19 pin)
HDMI AV output (To TV (ARC)) 1
Output connector Type A (19 pin)
Digital audio input
Optical (TV) 1
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only Optical (TV) input, LPCM)
Audio format LPCM, Dolby Digital, DTS
Speaker output
(Front L, R) 2
SUBWOOFER SECTION
1 way, 1 speaker system (Bass reflex type)
Woofer 16 cm cone typek1
MAIN UNIT GENERAL
Power consumption 52 W
In standby condition 0.1 W
Power supply
For EG/EB/GN AC 220 V to 240 V, 50 Hz
For GS AC 110 V to 127 V/220 V to 240 V, 50/60 Hz
Dimensions (WkHkD)
180 mmk408 mmk305 mm
Mass 5.6 kg
Operating temperature range
0
o
C to 40
o
C
Operating humidity range
20 % to 80 % RH (no condensation)
FRONT SPEAKER
SECTION
2 way, 2 speaker system (Bass reflex type)
Woofer 3.5 cmk10 cm cone typek1
Tweeter 2.5 cm semi dome typek1
SPEAKER GENERAL
Horizontal Placement using the Stands
Dimensions (WkHkD)
800 mmk89 mmk75 mm
Mass 1.4 kg
Horizontal Placement using the Speaker Feet
Dimensions (WkHkD)
800 mmk51 mmk58 mm
Mass 1.36 kg
Horizontal Placement (for wall mount)
Dimensions (WkHkD)
800 mmkApprox. 49 mmk58 mm
Mass 1.36 kg
Vertical Placement using the Base Stands
Dimensions (WkHkD)
135 mmk398 mmk135 mm
Mass 0.64 kg
Vertical Placement (for wall mount)
Dimensions (WkHkD)
Approx. 49 mmk380 mmk58 mm
Mass 0.59 kg
Model number suffix and destination
EB The United Kingdom and Ireland
EG Continental Europe
GN Australia and New Zealand
GS South East Asia and the Middle East
SC-HTB15EGEBGNGS_VQT3R83.book Page 29 Tuesday, June 28, 2011 2:34 PM

Panasonic SC-HTB15 Specifications

General

Audio decoders	Dolby Digital, Dolby Pro Logic II, DTS
RMS rated power	240 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Impedance	6 Ω
Woofer diameter	160 mm
Tweeter diameter	25 mm
Soundbar speaker RMS power	120 W
Total Harmonic Distortion (THD)	10 %
Subwoofer connectivity	Wired
Receiver included	No
Product color	Black
Consumer Electronics Control (CEC)	VIERA Link
Apple docking compatibility	Not supported
Soundbar dimensions (WxDxH)	800 x 58 x 49 mm
Subwoofer dimensions (WxDxH)	180 x 305 x 408 mm
HDMI in	2
HDMI ports quantity	3
Digital audio optical in	1
Power source	AC
AC input voltage	220-240 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	52 W

Weight and Dimensions

Soundbar weight	1360 g
Subwoofer weight	5600 g
