Making the connections
Connect the AC mains lead only after all other connections have been made.
To household
mains socket
Black (·)
Red (ª)
Black (·)
Red (ª)
Incorrect connection can damage the unit.
Antenna connections
AM loop antenna
Insertion of connector
Even when the connector is perfectly inserted,
depending on the type of inlet used, the front
part of the connector may jut out as shown in the
drawing. However there is no problem using the
unit.
Connector
Appliance inlet
For your reference
To save power when the unit is not to be used for
a long time, unplug it from the household mains
socket. You will need to reset some memory
items after plugging in the unit.
Note:
• The included AC mains lead is for use with this
unit only.
Do not use it with other equipment.
• Do not use an AC mains lead from other
equipment.
AC mains lead connections
READ THE CAUTION FOR AC MAINS LEAD
ON PAGE 3 BEFORE CONNECTION.
