Overview of controls
Do the procedures with the remote control. You can also use the buttons on the main unit if they
are the same.
A Standby/on switch [`], [1 ]
Press to switch the unit from on to standby mode or vice versa. In standby mode, the unit is still
consuming a small amount of power.
B Select the audio source
On the main unit:
Press [SELECTOR] repeatedly to select the source:
[PM702]
[PM700]
To start Bluetooth
®
pairing, press and hold [– PAIRING].
C Basic playback control
D View the setup menu
E View the content information
F Select or confirm the option
Skip MP3 albums
G Open or close the disc tray
H Decrease the brightness of the display panel
To cancel, press the button again.
I Adjust the volume level
Rear
