Panasonic SC-PM702 - Specifications

28
TQBM0877
D:\New folder\PM700\Source\xml\PM700\PM700EB.EG_TQBM0877_EN.fm
Specifications
█ General
Dimensions (W x H x D)
SA-PM702 210 mm x 114 mm x 266 mm
SA-PM700 210 mm x 114 mm x 261 mm
SB-PM700 145 mm x 226 mm x 195 mm
Mass
SA-PM702/SA-PM700 2.2 kg
SB-PM700 1.8 kg
Operating temperature range 0 °C to +40 °C
Operating humidity range 35% to 80% RH (no condensation)
█ Amplifier section
RMS output power
Front Ch (both ch driven) 40 W per channel (6 Ω), 1 kHz, 10% THD
Total RMS power 80 W
█ Disc section
Disc played (8 cm or 12 cm) CD, CD-R/RW
Pick up
Wavelength 790 nm (CD)
NORSK
Bølgelengde 790 nm (CD)
Laserstyrke Ingen farlig stråling sendes ut
Format CD-DA, MP3
*
1
Maximum number of folders (albums) 255
Maximum number of files (songs) 999
*
1
MPEG-1 Layer 3, MPEG-2 Layer 3
█ Tuner section
Frequency modulation (FM)
Preset memory 30 stations
Frequency range 87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals [PM700] 75 Ω (unbalanced)
Power supply AC 220 V to 240 V, 50 Hz
Power consumption 27 W
Power consumption in standby mode (approximate)
With “BLUETOOTH STANDBY” set to “OFF” 0.3 W
With “BLUETOOTH STANDBY” set to “ON” 0.4 W
