Panasonic SD-ZB2502BXC - Replacement Parts Listing

45
8.2. REPLACEMENT PARTS LIST
Notes:Important safety notice
• Components identified by mark have special characteristics important for safety.
• " When replacing any of these components use only manufacturer's specified parts."
MODEL No.SD-ZB2502BXC
Safety Ref. No. Part No. Part Name & Description
Pcs/Set
Remarks
ZB2502BXC
<PARTS LIST>
1 ADA39E165-S0 Dispenser cover assy 1
2 ADD40E165-H2 Window of lid 1
3 ADY02E165-X0 Caution label 1
4 ADD04E165-S0 Dispenser cover 1
5 ADD35-143 Fixing Spring 2
6 ADD37E165 Magnet Plate B 1
7 ADD34E165 Seal rubber 1
8 ADD30E165-H0 Middle Lid 1
9 ADA44E165-H0 Dispenser B assy 1
10 ADD79E165-K1 Top Lid assy 1
11 ADY06E165-K1 Menu label 1
12 ADD97E160 Kneading blade A unit 1 For Rye
13 ADD96E160 Kneading blade B unit 1
14 ADA12E165 Bread pan assy 1
15 ADD84E165 Bread pan 1
16 ASD191U103-K Packing 1
17 ADA29E165 Mounting shaft assy 1
18 ADB96E165K1S Upper frame 1
19 ADA40E165 Solenoid assy B 1 For Raisin
20 ASD850-108-W Spring A 2
21 ADA21E165 Solenoid assy 1 For Yeast
22 ADB16E165-K1 Hinge cover 1
23 ADE17E165 Heat insulator 1
24 ADR30E165 P.C.Board A assy 1
25 ADP10E165 Flat cable 1
26 ADT01E165 Base for P.C.B. 1
27 DR31E165 P.C.Board B assy 1
28 ADE09-163 Heater insulator A 1
29 ADE16-163 Fixing metal for heater 1
30 ADA22E165 Heater 1 240V-550W
31 ADE10E165 Heater insulator B 2
32 ADA25E165 Heater case base assy 1
33 ADE97A107 Connector lower unit 1
34 ADE98E165 Heater case base unit 1
35 DJ17A1151 Screw P 4
36 ADE96E165 Heater case unit 1 W/No.28-31
37 ADA11E165 Sensor assy 1
38 ADA30E165 Ground wire A assy 1
39 ADA17E165 Thermal fuse assy 1
Blowout temp. is 142 degrees of
centigrade's.
40 ADE03E165 Frame of insulator 1
41 AJ-236-20 Glass tape 1 20*50. Cut off to this size.
42 SD938-101AD 5 x 10 Screw R 4
43 ADE01E165 Angle 1
44 ADA10E147 Motor assy 1 W/TF
45 ADP50-143 Bind wire A 3
46 ADF05E165 Pulley B 1
47 ASD867-100AW Lock washer 1
48 SD873-100AZ Hexagon nut (special) 1
49 ADF01E165 Belt 1
50 ADB01E165 Body 1
51 ADY01E165 Rating plate 1
52 ADB02E165-K1 Bottom frame 1
53 ADB09E160-K0 Rubber leg 4
54 DJ14E160 Screw 4
55 ADA24E165 Power cord assy 1
56 AJ-236-20 Glass tape 1
57 ADP07E165-K1 Cord support 1
58 ASD911U112P0 Measuring spoon 1
59 ASD917-108-K Measuring cup 1
<SMALL STANDARDIZED METAL PARTS>
A XTB4+10BFJ Screw 3
B XTB4+14BFC Screw 6
