13
LSQT1346
28 SD card slot (l 22)
29 Tripod receptacle
30 Battery holder (l 15, 17)
31 Battery release lever [BATTERY]
(l 15, 17)
Tripod receptacle
This is a hole for attaching the unit to the
optional tripod.
≥ When the tripod is used, the SD card slot
cover cannot be opened. Insert an SD card
and the battery before attaching this unit to
the tripod. (l 15, 22)
29 30
31
28
SDR-H60&40EP-LSQT1346_eng.book 13 ページ ２００８年２月２５日 月曜日 午後３時３３分
