Panasonic SU-HTB550GK

143
19.1.5. Mechanical Replacement Parts List
19.1.5.1. Main Unit (SU-HTB550)
19.1.5.2. Front Speakers (SB-HTB550)
Safety Ref.
No.
Part No. Part Name &
Description
QTY Remarks
CABINET AND CHAS-
SIS
1 REE1614 40P FFC (DAMP-
MAIN)
1
2 REE1623 9P FFC (SMPS-MAIN) 1
3 REE1629 11P FFC (PANEL-
MAIN)
1
4 REE1630 17P FFC (WIRELESS-
MAIN)
1
6 REX1461 6P CABLE WIRE(SMPS
- D-AMP)
1
8 REX1469 2P CABLE WIRE
(POWER BUTTON -
MAIN)
1
9 REX1470 3P CABLE WIRE
(PANEL - BUTTON)
1
11 RGR0423B-F REAR PANEL 1 GS,GSX
11 RGR0423B-H REAR PANEL 1 GK
12 RYP1694D-K FRONT PANEL ASSY 1
12-1 RGU2774-K POWER BUTTON 1
13 RGU2775-K1 VOLUME BUTTON 1
15 RHD26046 SCREW 6
16 RHD30007-K2J SCREW 2
17 RHD30102-1 SCREW 2
18 RHD30119-S SCREW 12
19 RHD30172 SCREW 8
20 RHDX261002 SCREW 3
21 RKA0253-H LEG CUSHION 4
22 RMCX1008 WIRELESS GROUND
SPRING
1
23 RMK0804 BOTTOM CHASSIS 1
24 RMQ2001-1 TRANSMITTER HOLDER 1
25 RMQ2003-1 VOLUME BUTTON
BRACKET
1
26 RMZ1105-1 HEAT SINK SPACER 3
27 RMZ1264 SMPS INSULATOR
BOTTOM
1
28 RFKKUHTB350P TOP PANEL ASS’Y 1
29 RSCX1060 RADIATOR SHEET 1
Safety Ref.
No.
Part No. Part Name &
Description
QTY Remarks
CABINET AND CHAS-
SIS
1 RFKABHTB550P SPEAKER UNIT 1 P
1 RFKABHTB550G SPEAKER UNIT 1 GK
2 RFKGBHTB550P FRONT CABINET
ASS’Y
1
3 RYQ0955-K REAR CABINET ASSY 1 P
3 RYQ0988-K REAR CABINET ASSY 1 GK
3-1 K4BC02B00017 TERMINAL 1
3-2 XTB3+10JFJK SCREW 1
4 RYQ0885-K PORT ASS’Y 1
5 REX1467 TRANSIT WIRE 1
6 RMF0458-J TWEETER SHEET 1
7 RMF0558 EVA PACKING
(WOOFER SPEAKER)
1
8 RMQ1997 EVA PACKING (PORT
ASS’Y)
1
9 XTB3+10JFJK SCREW 25
Safety Ref.
No.
Part No. Part Name &
Description
QTY Remarks
