Panasonic SU-HTB550GK

29
11.1. Disassembly flow chart
The following chart is the procedure for disassembling the casing and inside parts for internal inspection when carrying out the ser-
vicing.
To assemble the unit, reverse the steps shown in the chart below.
11.1.1. Main Unit (SU-HTB550)
11.1.2. Front Speakers (SB-HTB550)
