40
PC input signals
Applicable input signals for Mini D-sub 15P (Component) / Mini D-sub 15P (RGB) (
∗
Mark)
Signal name
Horizontal
frequency (kHz)
Vertical
frequency (Hz)
Mini D-sub 15P
(Component)
Mini D-sub 15P
(RGB)
1 525 (480) / 60i 15.73 59.94
∗∗
2 525 (480) / 60p 31.47 59.94
∗
∗
1
3 625 (575) / 50i 15.63 50.00
∗∗
4 625 (575) / 50p 31.25 50.00
∗∗
5 750 (720) / 60p 45.00 60.00
∗∗
6 750 (720) / 50p 37.50 50.00
∗∗
7 1,125 (1,080) / 60i 33.75 60.00
∗∗
8 1,125 (1,080) / 50i 28.13 50.00
∗∗
9 1,125 (1,080) / 24p 27.00 24.00
∗∗
10 1,125 (1,080) / 24sF 27.00 47.92
∗∗
11 1,125 (1,080) / 25p 28.13 25.00
∗∗
12 1,125 (1,080) / 30p 33.75 30.00
∗∗
13 1,250 (1,080) / 50i 31.25 50.00
∗∗
14 640 × 400 @70 Hz 31.46 70.07
∗
15 640 × 480 @60 Hz 31.47 59.94
∗
2
16 640 × 480 @72 Hz 37.86 72.81
∗
17 640 × 480 @75 Hz 37.50 75.00
∗
18 640 × 480 @85 Hz 43.27 85.01
∗
19 852 × 480 @60 Hz 31.47 59.94
∗
2
20 800 × 600 @56 Hz 35.16 56.25
∗
21 800 × 600 @60 Hz 37.88 60.32
∗
22 800 × 600 @72 Hz 48.08 72.19
∗
23 800 × 600 @75 Hz 46.88 75.00
∗
24 800 × 600 @85 Hz 53.67 85.06
∗
25 1,024 × 768 @60 Hz 48.36 60.00
∗
26 1,024 × 768 @70 Hz 56.48 70.07
∗
27 1,024 × 768 @75 Hz 60.02 75.03
∗
28 1,024 × 768 @85 Hz 68.68 85.00
∗
29 1,152 × 864 @75 Hz 67.50 75.00
∗
30 1,280 × 960 @60 Hz 60.00 60.00
∗
31 1,280 × 960 @85 Hz 85.94 85.00
∗
32 1,280 × 1,024 @60 Hz 63.98 60.02
∗
33 1,280 × 1,024 @75 Hz 79.98 75.03
∗
34 1,280 × 1,024 @85 Hz 91.15 85.02
∗
35 1,600 × 1,200 @60 Hz 75.00 60.00
∗
36 1,600 × 1,200 @65 Hz 81.25 65.00
∗
37 1,066 × 600 @60 Hz 37.88 60.32
∗
38 1,366 × 768 @60 Hz 48.36 60.00
∗
39 Macintosh13” (640 × 480) 35.00 66.67
∗
40 Macintosh16” (832 × 624) 49.72 74.54
∗
41 Macintosh21” (1,152 × 870) 68.68 75.06
∗
∗
1:
When selected the RGB format and 525p signal input to the Mini D-sub 15P terminal, it is recognized as VGA 60Hz signal.
∗2:
When inputted VGA 60Hz format signal from the other than Mini D-sub 15P terminal, it is recognized as 525p signal.
Note: Signals without above specification may not be displayed properly.
