Panasonic TH-42PW3

11
Connections
How to connect the AV Input Terminals
S-VIDEO Signal Connection
(Example) When connecting a S-Video VCR
(DVD Player / S-VIDEO VCR)
Audio
OUT
Video
OUT
S-Video
OUT
RL
VIDEO
Video input to
S-VIDEO socket
Audio input to
L/R sockets
AUDIO
2×RCA Audio cables
S-VIDEO
VIDEO
L
R
AUDIO
AV IN
Luminance earth
Luminance in
Chrominance earth
Chrominance in
S-VIDEO 4 pin socket
(VCR)
AV2
Video input to
BNC socket
Audio input to
L/R sockets
(DVD / Satellite Receiver)
AV1/TV
Video input to
BNC socket
21P Scart Plug
RCA-BNC
adapter plug
Audio input to L/R sockets
S-VIDEO
VIDEO
L
R
AUDIO
AV IN
21P Scart Plug
VIDEO Signal Connection
Note:
21 pin connectors and 21 pin scart plugs are connectors used in Europe.
