13
Connections
Notes:
(1) Additional equipment and cables shown are not supplied with this set.
(2) 21 pin connectors and 21 pin scart plugs are connectors used in Europe.
The cable shown is for connection detail only. If you wish to use this connection method, please consult your Dealer
for the cable.
Select sync oj VIDEO (see page 30).
(DVD / Satellite Receiver)
AV2
Video input to
BNC socket
RCA-BNC
adapter plug
S-VIDEO
VIDEO
L
R
AUDIO
AV IN
VD HD P
R
/C
R
/R P
B
/C
B
/B Y/G
L
R
COMPONENT/RGB IN
AUDIO
RCA-BNC
adapter plug
VIDEO Signal Connection
To Next Page
