65
Specifi cations
TH-50PB2U TH-65PB2U
Power Source
110 - 127 V AC, 50/60 Hz
Power Consumption
Rated Power Consumption 400 W 550 W
Stand-by condition 0.4 W 0.4 W
Power off condition 0.2 W 0.2 W
Plasma Display panel
Drive method : AC type 50-inch,
16:9 aspect ratio
Drive method : AC type 65-inch,
16:9 aspect ratio
Screen size
43.5” (1,105 mm) (W) × 24.4” (622 mm) (H)
× 49.9” (1,268 mm) (diagonal)
56.4” (1,434 mm) (W) × 31.7” (806 mm) (H)
× 64.7” (1,645 mm) (diagonal)
(No.of pixels) 2,073,600 (1,920 (W) × 1,080 (H))
[5,760 × 1,080 dots]
Operating condition
Temperature 32 °F - 104 °F (0 °C - 40 °C)
Humidity 20 % - 80 %
Applicable signals
Color System NTSC, PAL, PAL60, SECAM, Modifi ed NTSC
Scanning format 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 60p · 50i · 50p
· 24p · 25p · 30p · 24sF, 1250 (1080) / 50i
PC signals VGA, SVGA, XGA, SXGA
UXGA ···· (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
Connection terminals
AV IN
VIDEO
AUDIO 1 IN
BNC
Stereo mini jack (M3) × 1
1.0 Vp-p (75 Ω)
0.5 Vrms, Shared with COMPONENT/RGB IN
HDMI TYPE A Connector
COMPONENT/RGB IN
Y/G
P
B/CB/B
P
R/CR/R
AUDIO 1 IN
BNC
BNC
BNC
Stereo mini jack (M3) × 1
with sync 1.0 Vp-p (75 Ω)
0.7 Vp-p (75 Ω)
0.7 Vp-p (75 Ω)
0.5 Vrms, Shared with VIDEO
DVI-D IN
AUDIO 2 IN
DVI-D 24 Pin
Content Protection
Stereo mini jack (M3) × 1
Compliance with DVI Revision 1.0
Compatible with HDCP 1.1
0.5 Vrms, Shared with PC IN
PC IN
AUDIO 2 IN
High-Density Mini D-sub 15 Pin
Stereo mini jack (M3) × 1
Y or G with sync 1.0 Vp-p (75 Ω)
Y or G without sync 0.7 Vp-p (75 Ω)
P
B
/C
B
/B: 0.7 Vp-p (75 Ω)
P
R
/C
R
/R: 0.7 Vp-p (75 Ω)
HD/VD: 1.0 - 5.0 Vp-p (high impedance)
0.5 Vrms, Shared with DVI-D IN
SERIAL
External Control Terminal
D-sub 9 Pin RS-232C compatible
PEN ADAPTER For electronic pen adapter
MEMORY/(CHARGE) For USB memory/electronic pen charging
CHARGE For electronic pen charging
WIRELESS MODULE for Wireless module (ET-WM200U)
LAN RJ45 10BASE-T/100BASE-TX, compatible with PJLink™
EXT SP
6 Ω, 16 W [8 W + 8 W] (10 % THD) 8 Ω, 20 W [10 W + 10 W] (10 % THD)
Sound
Speakers
4.8” (120 mm) × 1.6” (40 mm) × 2 pcs
Audio Output
20 W [10 W + 10 W] (10 % THD)
Dimensions (W × H × D)
47.7” (1,210 mm) × 28.5” (724 mm) × 3.5” (89 mm) 61.2” (1,554 mm) × 36.5” (925 mm) × 3.9” (99 mm)
Mass (weight)
main unit only
approx. 75.0 lbs approx. 127.9 lbs
Note:
Design and specifi cations are subject to change without notice. Mass and dimensions shown are approximate.
