142
TH-65PF11UK
14.2.2. Electrical Replacement Parts List
Safety Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
F201 HU216005BEP FUSE 1
F301 HU216005BEP FUSE 1
F601 HU215010BEP FUSE 1
F602 HU215010BEP FUSE 1
F801 HU215010BEP FUSE 1
F802 HU215010BEP FUSE 1
F803 HU382T2P FUSE 1
A601 AYRA362MSV7T ARRESTOR 1
A602 AYRA362MSV7T ARRESTOR 1
C10 K1MN20BA0231 20P CONNECTOR 1
C11 K1MN68BA0266 68P CONNECTOR 1
C20 K1MN20BA0266 20P CONNECTOR 1
C21 K1MN68BA0266 68P CONNECTOR 1
C22 K1MN68BA0266 68P CONNECTOR 1
C23 K1MN68BA0266 68P CONNECTOR 1
C32 K1KA04AA0728 4P CONNECTOR 1
C33 K1MN68BA0266 68P CONNECTOR 1
C41 K1MN80BA0076 80P CONNECTOR 1
C43 K1KA10A00416 10P CONNECTOR 1
C45 K1KA04AA0728 4P CONNECTOR 1
C50 K1MN20BA0266 20P CONNECTOR 1
C51 K1MN80BA0076 80P CONNECTOR 1
C52 K1MN68BA0266 68P CONNECTOR 1
C53 K1MN68BA0266 68P CONNECTOR 1
C60 K1MN20BA0231 20P CONNECTOR 1
C61 K1MN68BA0266 68P CONNECTOR 1
C201 ACKZE1H220T 50V 22PF 1
C202 ACCC3FD470JP 3kV 47PF 1
C203 ACCC3FD470JP 3kV 47PF 1
C204 ACMPEF12333H 1250V 0.033PF 1
C205 ACMPEF12333H 1250V 0.033PF 1
C207 ACDE1SL471JP 1kV 470PF 1
C208 ACDE1SL471JP 1kV 470PF 1
C209 ECQV1H224JL P 0.22UF, J,
50V
1
C210 ECQV1H224JL P 0.22UF, J,
50V
1
C231 ACKZE1H220T 50V 22PF 1
C232 ACKZE1H220T 50V 22PF 1
C251 ECQV1H104JL P 0.1UF, J, 50V 1
C252 ECQV1H224JL P 0.22UF, J,
50V
1
C254 ECQE2223SKF 250V 0.022PF 1
C255 ECQE2223SKF 250V 0.022PF 1
C256 ACKMQ220901Z 220V 900PF 1
C257 ACKMQ220901Z 220V 900PF 1
C258 ACKMQ220901Z 220V 900PF 1
C259 ACKMQ220901Z 220V 900PF 1
C301 ACKZE1H220T 50V 22PF 1
C302 ACRR3DD101K7 2kV 100PF 1
C303 ACRR3DD101K7 2kV 100PF 1
C304 ACMPEF12473H 1250V 0.047PF 1
C305 ACCK1B681KP 1kV 680p 1
C306 ACCK1B681KP 1kV 680p 1
C352 ACKZE1E182ST 25V 1800PF 1
C354 ECQV1H224JL P 0.22UF, J,
50V
1
C355 ECQV1H823JL 50V 0.082PF 1
C357 ACKZE1E471LT 25V 470PF 1
C358 ACKZE1E471LT 25V 470PF 1
C401 ECQE2104SKF 250V 0.1PF 1
C402 ECQE2104SKF 250V 0.1PF 1
C403 EETHC2C471HX 160V 470PF 1
C404 ACKZE1H101T 50V 100PF 1
C406 EETHC2A122JJ 100V 1200PF 1
C409 ECQE2104SKF 250V 0.1PF 1
C451 ACKZE1A471C 10V 470PF 1
C500 ACKZE1H221T 50V 220PF 1
C501 ECQU2A103MLA P 0.01UF,
M,250V
1
C503 ACKMQ2W560T 450V 56PF 1
C504 ACKZE1H220T 50V 22PF 1
C505 ECQV1H224JL P 0.22UF, J,
50V
1
C506 ACKZE1H100T 50V 10PF 1
C507 ACKZE1H221T 50V 220PF 1
C508 ACKZE1H220T 50V 22PF 1
C551 ACKZE1A102LC 10V 1000PF 1
C555 ACKZE1E470T 25V 47PF 1
C558 ECQV1H224JL P 0.22UF, J,
50V
1
C559 ECQV1H474JL P 0.47UF, J,
50V
1
C602 ECQU2A105MLA P 1UF, 250V 1
C603 ECKENA221KBR C 221P 250V 1
C604 ECKENA221KBR C 221P 250V 1
C605 ACDE1R102K7 1kV 680p 1
C606 AC4MPH105KA3 450V 1PF 1
C610 ECQV1H105JL 50V 1PF 1
C611 ACKZE1H220T 50V 22PF 1
C612 EETHD2W301LZ 450V 300PF 1
C613 EETHD2W301LZ 450V 300PF 1
C615 ECKENA101KBR C 100P 250V 1
C620 ECKENA331KBR C 330P 250V 1
C621 ECKENA331KBR C 330P 250V 1
C625 ACRR3AD222KP 1kV 2200PF 1
C701 ACKZE1A471C 10V 470PF 1
C702 ECQV1H103JL2 50V 0.01PF 1
C801 ECQU2A105MLA P 1UF, M,250V 1
C801 F1K1C1060004 C 0.010UF, 16V 1
C802 ECJ3YB1E106M C 10 UF, K, 25V 1
C802 ECKENA101KBR C 100P 250V 1
C803 ECKENA101KBR C 100P 250V 1
C803 F1H1H472A970 C 4700PF, K,
50V
1
C804 ECQU2A105MLA P 1UF, M,250V
C805 F1H1E104A129 C 0.1UF, 25V 1
C807 ACDE1R102K7 1kV 680p 1
C808 AC4MPH105KA3 450V 1PF 1
C809 ACRR3AD222KP 1kV 2200PF 1
C809 F1K1C1060004 C 0.010UF, 16V 1
C810 ECQV1H105JL 50V 1PF 1
C810 F1G1E103A123 C 0.010UF, K,
16V
1
C811 ACKZE1H220T 50V 22PF 1
C812 ECJ3YB1E106M C 10 UF, K, 25V 1
C812 EETHD2W301LZ 450V 300PF 1
C814 ECKENA101KBR C 100P 250V 1
C815 ECKENA101KBR C 100P 250V 1
C815 F1H1E104A129 C 0.1UF, 25V 1
Safety Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
