12
Touchscreen
Calibration by a standard user
NOTE
Perform the following calibration for each user.
1 Run [Tablet PC Settings].
Click (Start) - [Control Panel] - [Hardware and Sound] - [Tablet PC Settings].
2 Click [Calibrate].
3 Using the stylus, touch each of the “+” target marks one by one, and then click [OK].
Perform the calibration for the orientation to be used.
1 Run [Touch Screen Calibration Utility].
Click [start] - [All programs] - [Fujitsu Touch Panel (USB)] - [Touch Screen Calibration Utility].
2 Using the stylus, touch each of the 12 “+” target marks one by one until it blinks, and then
press
Enter
.
3 Press
Enter
.
NOTE
Perform the touchscreen calibration for each user.
