37
PC Card / ExpressCard
You can insert the following cards.
ExpressCard/34 or ExpressCard/54 to the ExpressCard slot (A)
PC Card Type I (3.3 mm) or II (5.0 mm) to the PC Card slot (B)
For model with Smart Card slot ( page 43)
NOTE
The following types of card are not supported:
PC Card Type III (10.5 mm), ZV card, SRAM card, FLASH ROM card (excluding ATA interface type), and other cards
that require 12 V of operating voltage.
Do not start up Windows with a storage type of CardBus PC card attached. An error may occur.
Preparation
Attach the device for the media containing the card driver (e.g., CD-ROM). Equipment connected to the multimedia
pocket cannot be recognized if connected after the card driver installation screen appears.
To insert the card
1 Slide the latch (C) and open the cover.
Inserting/Removing the Card
To Next Page
