6.2. Wire Dressing and Connections
CONNECTION 1 2 3 4 5 6 7 8 9 10 11 12
1 INV - P 2
2 A2~P4
3 A1~P3
4 G3~K1
5 G1~A4
6 G2~A5
7 V1~A7
8 A 3 ~ SPEAKER (L)
9 A 3 ~ SPEAKER (R)
10 P1~SW2
11 INV ~ A 6
