Ref.
No.
Part No. Part Name & Description Remarks
1 EAS16S07B SPEAKER
J0KF00000018 FERRITE CORE
J0KG00000114 CORE CLAMPER
J0KG00000139 CORE CLAMPER
K1PY30YA0005 LVDS WIRE
K2CJ2YY00007 AC CORD
L5EDD6Q00028 LCD PANEL
2 N2QAKB000065 REMOTE CONTROL
3 TBL4GA0007 PEDESTAL
4 TBM4GC194 MODEL NAME PLATE
5 TBX4GA00102 POWER BUTTON
TBX4GA00201 CONTROL BUTTON
TKK4GC5001-1 LED PANEL
6 TKP4G11745 AC CORD BRACKET
7 TKP4GA00201 CONTROL PANEL
TKP4GA00301 G PCB BRACKET
8 TKR4GA01201 ORNAMENT PANEL
NLA TZT/A10NND A PRINT
NLA TNP4G432AB K BOARD
NLA TNP4G433AS P BOARD
NLA TNP4G435AB G BOARD
NLA TNP4G436AB V BOARD
NLA TNP4G437AB SW BOARD
TPD4GA0074 BOTTOM CUSHION
TPE4G14037 SET COVER
9 TQZ4GB061 FAN BAG
10 TTU4GA0103-1 BACK COVER
11 TTY4GA0044 CABINET
TXAKP020NGE K BOARD BRACKET
TXFPC010NND CARTON
TXFPD010NKE TOP CUSHION
TXFPD030NKE PEDESTAL CUSHION
CAPACITORS
C1003 ECEA1CKS220 E 22UF, 16V
C1006 ECEA0JKS470 E 47UF, 6.3V
C1007 ECJ1VB1H103K C 0.01UF, K, 50V
C1168 ECJ1VB1C104K C 0.1UF, K, 16V
C1181 ECJ1VB1H102K C 1000PF, K, 50V
C1182 ECJ1VB1H102K C 1000PF, K, 50V
C1185 ECJ1VB1H102K C 1000PF, K, 50V
C1186 ECJ1VB1H102K C 1000PF, K, 50V
C1801 ECJ1VB1H103K C 0.01UF, K, 50V
C1802 ECJ1VB1H472K C 4700PF, K, 50V
C1803 ECJ1VC1H101J C 100PF, J, 50V
C1804 ECJ1VB1H103K C 0.01UF, K, 50V
C1822 F1G1A1040006 C 0.1UF, 10V
C1828 EEEHB1C470P E 47UF, 16V
C1831 F1G1A1040006 C 0.1UF, 10V
C1834 ECJ2FB1C474K C 0.47UF, K, 16V
C1835 ECJ1VB1C563K C 0.056UF, K, 16V
C1836 ECJ1VB1C104K C 0.1UF, K, 16V
C1837 F1H1H103A013 C 0.01UF, 50V
C1839 ECJ1VC1H101J C 100PF, J, 50V
C1840 ECJ1VF1A105Z C 1UF, Z, 10V
C1842 F1H0J1050013 C 1UF, 6.3V
C1843 F1H0J1050013 C 1UF, 6.3V
C1844 EEEHB0G470R E 47UF, 4V
C1845 EEEHB0G470R E 47UF, 4V
C1850 F1G1A1040006 C 0.1UF, 10V
C1851 F1G1A1040006 C 0.1UF, 10V
C1852 EEEHB0G470R E 47UF, 4V
C1853 EEEHB0G470R E 47UF, 4V
C1854 ECJ1VB1H104K C 0.1UF, K, 16V
C1855 F2A1C101A310 E 100UF, 16V
C1856 EEUFC1A471B E 470UF, 10V
C1858 ECJ1VB1C104K C 0.1UF, K, 16V
C1865 ECJ1VF1A105Z C 1UF, Z, 10V
C1866 ECJ1VF1A105Z C 1UF, Z, 10V
C1867 ECJ1VF1A105Z C 1UF, Z, 10V
C1868 ECJ1VF1A105Z C 1UF, Z, 10V
C1869 EEEHB1C470P E 47UF, 16V
Ref.
No.
Part No. Part Name & Description Remarks
C1870 ECJ1VB1C104K C 0.1UF, K, 16V
C1951 ECJ1VB1H104K C 0.1UF, K, 50V
C1952 ECJ1VB1H104K C 0.1UF, K, 50V
C1954 EEEHB0J101P E 100UF, 6.3V
C2067 ECJ1VB1A105K C1UF,K,10V
C2068 ECJ1VB1A105K C1UF,K,10V
C2101 ECJ2FB1E105K C1UF,K,25V
C2102 ECJ2FB1E105K C1UF,K,25V
C2103 ECJ2FB1E105K C1UF,K,25V
C2106 ECJ2FB1E105K C1UF,K,25V
C2109 ECJ2FB1E105K C1UF,K,25V
C2110 ECJ2FB1E105K C1UF,K,25V
C2111 ECJ2FB1E105K C1UF,K,25V
C2112 ECJ2FB1E105K C1UF,K,25V
C2113 ECJ2FB1E105K C1UF,K,25V
C2114 ECJ2FB1E105K C1UF,K,25V
C2115 ECJ2FB1E105K C1UF,K,25V
C2116 ECJ1VB1C224K C 0.22UF, K, 16V
C2117 ECJ1VB1E104K C 0.1UF, K, 50V
C2118 ECJ1VB1C224K C 0.22UF, K, 16V
C2119 ECJ1VB1E104K C 0.1UF, K, 50V
C2120 ECJ2FB1E105K C1UF,K,25V
C2122 ECJ1VB1C224K C 0.22UF, K, 16V
C2124 ECJ1VB1C224K C 0.22UF, K, 16V
C2125 ECJ1VB1E104K C 0.1UF, K, 50V
C2126 ECJ1VB1E104K C 0.1UF, K, 50V
C2129 F2A1C102A252 E 1000UF, 16V
C2138 ECJ1VB1E104K C 0.1UF, K, 50V
C2139 F2A1E1010073 E 100UF, 25V
C2141 F1H1H103A013 C 0.01UF, 50V
C2142 EEEHB0J101P E 100UF, 6.3V
C2143 EEEHB0J101P E 100UF, 6.3V
C2144 F1H0J1050013 C1UF,6.3V
C2145 EEEHB1C470P E 47UF, 16V
C2146 ECJ2FB1E105K C1UF,K,25V
C2147 ECJ2FB1E105K C1UF,K,25V
C2163 ECJ1VB1E104K C 0.1UF, K, 50V
C2172 EEEHB0J101P E 100UF, 6.3V
C2173 ECJ2FB1E105K C1UF,K,25V
C2178 ECJ2FB1E105K C1UF,K,25V
C2223 F2A1E1010073 E 100UF, 25V
C2367 EEEHB1C101UP E 100UF, 16V
C3064 EEEHB0J331UP E 330UF, 6.3V
C3065 ECJ1VB1C104K C 0.1UF, K, 16V
C3067 F1J0J1060004 C 10UF, 6.3V
C3073 ECJ1VB1A105K C1UF,K,25V
C3076 ECJ1VB1A105K C1UF,K,25V
C3077 ECJ1VB1A105K C1UF,K,25V
C3200 ECJ1VB0J225K C 2.2UF, 6.3V
C3202 EEEHB1C101UP E 100UF, 16V
C3203 ECJ1VB1C224K C 0.22UF, K, 16V
C3204 EEEHB1C470P E 47UF, 16V
C3516 ECJ1VB0J475K C 4.7UF,K,6.3V
C3863 ECJ1VF1A105Z C1UF,Z,10V
C3866 EEEHB0J101P E 100UF, 6.3V
C3867 ECJ1VB1C104K C 0.1UF, K, 16V
C3870 ECJ1VF1H104Z C 0.1UF, Z, 50V
C3873 ECJ1VB1C104K C 0.1UF, K, 16V
C3874 ECJ1VB1C104K C 0.1UF, K, 16V
C4001 ECJ1VB1C104K C 0.1UF, K, 16V
C4004 ECJ1VB1C104K C 0.1UF, K, 16V
C4005 ECJ1VB1C104K C 0.1UF, K, 16V
C4006 ECJ1VB1C104K C 0.1UF, K, 16V
C4008 ECJ1VB1C104K C 0.1UF, K, 16V
C4009 F1J0J1060004 C 10UF, 6.3V
C4014 ECJ1VB1C104K C 0.1UF, K, 16V
C4015 ECJ1VB1C104K C 0.1UF, K, 16V
C4016 ECJ1VB1C104K C 0.1UF, K, 16V
C4017 ECJ1VB1C104K C 0.1UF, K, 16V
C4018 ECJ1VB1C104K C 0.1UF, K, 16V
C4019 F1J0J1060004 C 10UF, 6.3V
14.1. Electrical Replacement Parts List
