Panasonic TX-26LE8A - Page 61

Ref.
No.
Part No. Part Name & Description Remarks
R920 ERJ6GEYJ103 M 10KOHM,J,1/10W
R922 ERX1SJ2R2E M 2.2OHM,J, 1W
R923 ERJ6GEYJ753 M 75KOHM,J,1/10W
R924 ERJ6GEYJ753 M 75KOHM,J,1/10W
R926 ERDS2TJ204 C 200KOM,J, 1/4W
TRANSFORMERS
T801 ETS35LZ156AD SWITCHING TRANS
T802 ETS32CZ119AD SWITCHING TRANS
OTHERS
A1 K1KA14AA0178 CONNECTOR
A10 K1KA08AA0193 CONNECTOR
A12 K1KA04BA0055 CONNECTOR
A15 K1FB115A0025 CONNECTOR
A2 K1KA18AA0178 CONNECTOR
A4 K1KA05AA0193 CONNECTOR
A5 K1KA10AA0194 CONNECTOR
A6 K1KA04AA0190 CONNECTOR
A7 K1KA08AA0193 CONNECTOR
A8 K1KB30BA0071 CONNECTOR
A9 K1KA10AA0105 CONNECTOR
F841 K5D502BNA005 FUSE
FL4001 J0MAB0000169 LC FILTER
FL4002 J0MAB0000169 LC FILTER
FL4003 J0MAB0000169 LC FILTER
FL5001 F1J1A1050020 CERAMIC CAPACITOR
FL5002 F1J1A1050020 CERAMIC CAPACITOR
G1 K1KA05AA0193 CONNECTOR
G2 K1KA10AA0191 CONNECTOR
G3 K1KA02AA0180 CONNECTOR
JA1 ERJ8GEY0R00 M 0OHM,J, 1/8W
JA2 ERJ8GEY0R00 M 0OHM,J, 1/8W
JA29 ERJ8GEY0R00 M 0OHM,J, 1/8W
JA3 ERJ8GEY0R00 M 0OHM,J, 1/8W
JA4 ERJ8GEY0R00 M 0OHM,J, 1/8W
JA5 ERJ8GEY0R00 M 0OHM,J, 1/8W
JA6 ERJ8GEY0R00 M 0OHM,J, 1/8W
JA8 ERJ8GEY0R00 M 0OHM,J, 1/8W
JK3001 K4AK07A00002 AV TERMINAL
JK3002 K4AK04A00002 AV TERMINAL
JK3003 K4AK04A00001 AV TERMINAL
JK3006 K4AK04A00002 AV TERMINAL
JK3007 K4AK06A00002 AV TERMINAL
JK3501 K4AK18B00004 AV TERMINAL
JK5001 K1FY119D0003 HDMI TERMINAL
JK5002 K1FY119D0003 HDMI TERMINAL
JS1801 ERJ3GEY0R00 M 0OHM,J,1/16W
JS1805 ERJ3GEY0R00 M 0OHM,J,1/16W
JS1806 ERJ3GEY0R00 M 0OHM,J,1/16W
JS1808 ERJ2GE0R00X FIXED RESISTOR
JS1923 ERJ3GEY0R00 M 0OHM,J,1/16W
JS1925 ERJ3GEY0R00 M 0OHM,J,1/16W
JS2004 ERJ6GEY0R00 M 0OHM,J,1/10W
JS2005 ERJ6GEY0R00 M 0OHM,J,1/10W
JS2011 ERJ6GEY0R00 M 0OHM,J,1/10W
JS2012 ERJ6GEY0R00 M 0OHM,J,1/10W
JS2130 ERJ3GEY0R00 M 0OHM,J,1/16W
JS2131 ERJ3GEY0R00 M 0OHM,J,1/16W
JS2132 ERJ3GEY0R00 M 0OHM,J,1/16W
JS2133 ERJ3GEY0R00 M 0OHM,J,1/16W
JS2306 ERJ3GEY0R00 M 0OHM,J,1/16W
JS3501 ERJ6GEY0R00 M 0OHM,J,1/10W
JS3502 ERJ6GEY0R00 M 0OHM,J,1/10W
JS3503 ERJ6GEY0R00 M 0OHM,J,1/10W
JSP808 ERJ6GEY0R00 M 0OHM,J,1/10W
JSP814 ERJ6GEY0R00 M 0OHM,J,1/10W
JSP820 ERJ6GEY0R00 M 0OHM,J,1/10W
JSP821 ERJ6GEY0R00 M 0OHM,J,1/10W
JSP822 ERJ6GEY0R00 M 0OHM,J,1/10W
JSP823 ERJ6GEY0R00 M 0OHM,J,1/10W
JSP824 ERJ6GEY0R00 M 0OHM,J,1/10W
JSP825 ERJ6GEY0R00 M 0OHM,J,1/10W
K1 K1KA02BA0055 CONNECTOR
LF801 G0B153H00003 CHOKE COIL
Ref.
No.
Part No. Part Name & Description Remarks
LF803 G0B153H00003 CHOKE COIL
P1 K1KA02B00295 CONNECTOR
P2 K1KA10AA0194 CONNECTOR
P3 K1KA14AA0178 CONNECTOR
P4 K1KA18AA0178 CONNECTOR
PC801 B3PAA0000363 PHOTO COUPLER
PC802 B3PAA0000363 PHOTO COUPLER
RL801 K6B1CDA00028 RELAY
RM1001 PNA4701M06TV IC PHOTO DETECTOR
SN1001 B3L000000032 PHOTO DETECTOR
SW1 K1KA02A00720 CONNECTOR
SW2 K1KA02A00676 CONNECTOR
SW2500 EVQ11G05R SWITCH
SW2501 EVQ11G05R SWITCH
SW2502 EVQ11G05R SWITCH
SW2503 EVQ11G05R SWITCH
SW2504 EVQ11G05R SWITCH
SW841 ESB92DA1B SWITCH
TU101 ENG39E04GRF TUNER
V1 K1KA08BA0061 CONNECTOR
X4001 H0J202500011 CRYSTAL OSC
X5001 H0J283500018 CRYSTAL OSC
61
TX-26LE8A
