DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
R LCD BOTTOM MTG 29 TKZ0E9378
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17604
CARTON . TPC0E71601
TOP CUSHION . TPD0E0136
BOTTOM CUSHION . TPD0E0137-1
BOTTOM PAD . TPD0E9096
INSTRUCTION BOOKS
GERMAN . TQB0E0518A
ITALIAN . TQB0E0518C
SPANISH . TQB0E0518E
ENGLISH . TQB0E0518U
I.C.s
EEPROM IC1120 X24C26LE7FA
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AENE1
A6-H2 WIRE A6-H2 TXJ/A6AGNE
A12-H1 WIRE A12-H1 TXJ/A12AGNE
DIFFERENCES FOR MODEL TX--26LE7FA
EXPLODED VIEW
A P.C.B. 16 A-26LE7FA
AC CORD ASSY 17 TXASX02AERE
AV3 BRACKET 18 TKP0E16901
BACK COVER 19 TKU0E0194
CABINET 20 TTY0E0133
L LCD BOTTOM MTG 21 TKZ0E9377
L/R LCD MTG 23 TKZ0E9376
LCD BOTTOM MTG 24 TKZ0E9411
LCD PANEL 25 L5EDD6Q00027
LCD TOP MTG 26 TKZ0E9328
MODEL LABEL 27 TBM0E1045
PEDESTAL ASSY 28 TTX0E0003-2
R LCD BOTTOM MTG 29 TKZ0E9378
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17602
CARTON . TPC0E71601
TOP CUSHION . TPD0E0136
BOTTOM CUSHION . TPD0E0137-1
BOTTOM PAD . TPD0E9096
INSTRUCTION BOOKS
GERMAN . TQB0E0505A
DUTCH . TQB0E0505B
ITALIAN . TQB0E0505C
FRENCH . TQB0E0505D
SPANISH . TQB0E0505E
SWEDISH . TQB0E0505F
DANISH . TQB0E0505K
ENGLISH . TQB0E0505U
I.C.s
EEPROM IC1120 X24C26LE7FA
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AENE1
A6-H2 WIRE A6-H2 TXJ/A6AGNE
A12-H1 WIRE A12-H1 TXJ/A12AGNE
DIFFERENCES FOR MODEL TX--26LE7LA
EXPLODED VIEW
A P.C.B. 16 A-26LE7LA
AC CORD ASSY 17 TXASX02AENE
AV3 BRACKET 18 TKP0E16901
BACK COVER 19 TKU0E0194
CABINET 20 TTY0E0133
L LCD BOTTOM MTG 21 TKZ0E9377
L/R LCD MTG 23 TKZ0E9376
LCD BOTTOM MTG 24 TKZ0E9411
LCD PANEL 25 L5EDD6Q00027
LCD TOP MTG 26 TKZ0E9328
MODEL LABEL 27 TBM0E1108
PEDESTAL ASSY 28 TTX0E0003-2
R LCD BOTTOM MTG 29 TKZ0E9378
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17602
CARTON . TPC0E71601
TOP CUSHION . TPD0E0136
BOTTOM CUSHION . TPD0E0137-1
BOTTOM PAD . TPD0E9096
INSTRUCTION BOOKS
ENGLISH . TQB0E0517U
I.C.s
EEPROM IC1120 X24C26LE7LA
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AENE1
A6-H2 WIRE A6-H2 TXJ/A6AGNE
A12-H1 WIRE A12-H1 TXJ/A12AGNE
DIFFERENCES FOR MODEL TX--26LE7PA
EXPLODED VIEW
A P.C.B. 16 A-26LE7PA
AC CORD ASSY 17 TXASX02AERE
AV3 BRACKET 18 TKP0E16901
BACK COVER 19 TKU0E0194
CABINET 20 TTY0E0133
L LCD BOTTOM MTG 21 TKZ0E9377
L/R LCD MTG 23 TKZ0E9376
LCD BOTTOM MTG 24 TKZ0E9411
LCD PANEL 25 L5EDD6Q00027
LCD TOP MTG 26 TKZ0E9328
MODEL LABEL 27 TBM0E1093
PEDESTAL ASSY 28 TTX0E0003-2
R LCD BOTTOM MTG 29 TKZ0E9378
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17602
CARTON . TPC0E71601
TOP CUSHION . TPD0E0136
BOTTOM CUSHION . TPD0E0137-1
BOTTOM PAD . TPD0E9096
INSTRUCTION BOOKS
BULGARIAN . TQB0E0510M
ROMANIAN . TQB0E0510N
POLISH . TQB0E0510P
HUNGARIAN . TQB0E0510Q
CZECH . TQB0E0510R
ENGLISH . TQB0E0510U
I.C.s
EEPROM IC1120 X24C26LE7PA
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AENE1
A6-H2 WIRE A6-H2 TXJ/A6AGNE
A12-H1 WIRE A12-H1 TXJ/A12AGNE
DIFFERENCES FOR MODEL TX--32LE7F/SA
EXPLODED VIEW
A P.C.B. 16 A-32LE7FA
AC CORD ASSY 17 TXASX02AERE
AV3 BRACKET 18 TKP0E17001
26
