Panasonic TX-32LE7FA - Page 27

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
BACK COVER 19 TKU0E0195
CABINET 20 TTY0E0194-2
L LCD BOTTOM MTG 21 TKZ0E9382
L LCD MTG 22 TKZ0E9380
LCD BOTTOM MTG 24 TKZ0E9412
LCD PANEL 25 L5EDD8Q00036
LCD TOP MTG 26 TKZ0E9324-1
MODEL LABEL 27 TBM0E1109
PEDESTAL ASSY 28 TTX0E0002-2
R LCD BOTTOM MTG 29 TKZ0E9383
R LCD MTG 30 TKZ0E9381
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17604
FELT . TMK0E090
CARTON . TPC0E72001
TOP CUSHION . TPD0E0144
BOTTOM CUSHION . TPD0E0145-1
BOTTOM PAD . TPD0E9095
INSTRUCTION BOOKS
GERMAN . TQB0E0518A
ITALIAN . TQB0E0518C
SPANISH . TQB0E0518E
ENGLISH . TQB0E0518U
I.C.s
EEPROM IC1120 X24C32LE7FA
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AEOE1
A6-H2 WIRE A6-H2 TXJ/A6AGLE
A12-H1 WIRE A12-H1 TXJ/A12AGLE
DIFFERENCES FOR MODEL TX--32LE7FA
EXPLODED VIEW
A P.C.B. 16 A-32LE7FA
AC CORD ASSY 17 TXASX02AERE
AV3 BRACKET 18 TKP0E17001
BACK COVER 19 TKU0E0195
CABINET 20 TTY0E0137-2
L LCD BOTTOM MTG 21 TKZ0E9382
L LCD MTG 22 TKZ0E9380
LCD BOTTOM MTG 24 TKZ0E9412
LCD PANEL 25 L5EDD8Q00036
LCD TOP MTG 26 TKZ0E9324-1
MODEL LABEL 27 TBM0E1044
PEDESTAL ASSY 28 TTX0E0003-2
R LCD BOTTOM MTG 29 TKZ0E9383
R LCD MTG 30 TKZ0E9381
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17602
FELT . TMK0E090
CARTON . TPC0E72001
TOP CUSHION . TPD0E0144
BOTTOM CUSHION . TPD0E0145-1
BOTTOM PAD . TPD0E9095
INSTRUCTION BOOKS
GERMAN . TQB0E0505A
DUTCH . TQB0E0505B
ITALIAN . TQB0E0505C
FRENCH . TQB0E0505D
SPANISH . TQB0E0505E
SWEDISH . TQB0E0505F
DANISH . TQB0E0505K
ENGLISH . TQB0E0505U
I.C.s
EEPROM IC1120 X24C32LE7FA
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AEOE1
A6-H2 WIRE A6-H2 TXJ/A6AGLE
A12-H1 WIRE A12-H1 TXJ/A12AGLE
DIFFERENCES FOR MODEL TX--32LE7LA
EXPLODED VIEW
A P.C.B. 16 A-32LE7LA
AC CORD ASSY 17 TXASX02AENE
AV3 BRACKET 18 TKP0E17001
BACK COVER 19 TKU0E0195
CABINET 20 TTY0E0137-2
L LCD BOTTOM MTG 21 TKZ0E9382
L LCD MTG 22 TKZ0E9380
LCD BOTTOM MTG 24 TKZ0E9412
LCD PANEL 25 L5EDD8Q00036
LCD TOP MTG 26 TKZ0E9324-1
MODEL LABEL 27 TBM0E1107
PEDESTAL ASSY 28 TTX0E0003-2
R LCD BOTTOM MTG 29 TKZ0E9383
R LCD MTG 30 TKZ0E9381
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17602
FELT . TMK0E090
CARTON . TPC0E72001
TOP CUSHION . TPD0E0144
BOTTOM CUSHION . TPD0E0145-1
BOTTOM PAD . TPD0E9095
INSTRUCTION BOOKS
ENGLISH . TQB0E0517U
I.C.s
EEPROM IC1120 X24C32LE7LA
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AEOE1
A6-H2 WIRE A6-H2 TXJ/A6AGLE
A12-H1 WIRE A12-H1 TXJ/A12AGLE
DIFFERENCES FOR MODEL TX--32LE7P/SA
EXPLODED VIEW
A P.C.B. 16 A-32LE7PA
AC CORD ASSY 17 TXASX02AERE
AV3 BRACKET 18 TKP0E17001
BACK COVER 19 TKU0E0195
CABINET 20 TTY0E0194-2
L LCD BOTTOM MTG 21 TKZ0E9382
L LCD MTG 22 TKZ0E9380
LCD BOTTOM MTG 24 TKZ0E9412
LCD PANEL 25 L5EDD8Q00036
LCD TOP MTG 26 TKZ0E9324-1
MODEL LABEL 27 TBM0E1138
PEDESTAL ASSY 28 TTX0E0002-2
R LCD BOTTOM MTG 29 TKZ0E9383
R LCD MTG 30 TKZ0E9381
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17604
FELT . TMK0E090
CARTON . TPC0E72001
TOP CUSHION . TPD0E0144
BOTTOM CUSHION . TPD0E0145-1
BOTTOM PAD . TPD0E9095
INSTRUCTION BOOKS
BULGARIAN . TQB0E0546M
ROMANIAN . TQB0E0546N
27
