DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
POLISH . TQB0E0546P
HUNGARIAN . TQB0E0546Q
CZECH . TQB0E0546R
ENGLISH . TQB0E0546U
I.C.s
EEPROM IC1120 X24C32LE7PA
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AEOE1
A6-H2 WIRE A6-H2 TXJ/A6AGLE
A12-H1 WIRE A12-H1 TXJ/A12AGLE
DIFFERENCES FOR MODEL TX--32LE7PA
EXPLODED VIEW
A P.C.B. 16 A-32LE7PA
AC CORD ASSY 17 TXASX02AERE
AV3 BRACKET 18 TKP0E17001
BACK COVER 19 TKU0E0195
CABINET 20 TTY0E0137-2
L LCD BOTTOM MTG 21 TKZ0E9382
L LCD MTG 22 TKZ0E9380
LCD BOTTOM MTG 24 TKZ0E9412
LCD PANEL 25 L5EDD8Q00036
LCD TOP MTG 26 TKZ0E9324-1
MODEL LABEL 27 TBM0E1092
PEDESTAL ASSY 28 TTX0E0003-2
R LCD BOTTOM MTG 29 TKZ0E9383
R LCD MTG 30 TKZ0E9381
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17602
FELT . TMK0E090
CARTON . TPC0E72001
TOP CUSHION . TPD0E0144
BOTTOM CUSHION . TPD0E0145-1
BOTTOM PAD . TPD0E9095
INSTRUCTION BOOKS
BULGARIAN . TQB0E0510M
ROMANIAN . TQB0E0510N
POLISH . TQB0E0510P
HUNGARIAN . TQB0E0510Q
CZECH . TQB0E0510R
ENGLISH . TQB0E0510U
I.C.s
EEPROM IC1120 X24C32LE7PA
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AEOE1
A6-H2 WIRE A6-H2 TXJ/A6AGLE
A12-H1 WIRE A12-H1 TXJ/A12AGLE
DIFFERENCES FOR MODEL TX--R26LE7A
EXPLODED VIEW
A P.C.B. 16 A-R26LE7A
AC CORD ASSY 17 TXASX02AERE
AV3 BRACKET 18 TKP0E16901
BACK COVER 19 TKU0E0194
CABINET 20 TTY0E0133
L LCD BOTTOM MTG 21 TKZ0E9377
L/R LCD MTG 23 TKZ0E9376
LCD BOTTOM MTG 24 TKZ0E9411
LCD PANEL 25 L5EDD6Q00027
LCD TOP MTG 26 TKZ0E9328
MODEL LABEL 27 TBM0E1102
PEDESTAL ASSY 28 TTX0E0003-2
R LCD BOTTOM MTG 29 TKZ0E9378
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17602
CARTON . TPC0E71601
TOP CUSHION . TPD0E0136
BOTTOM CUSHION . TPD0E0137-1
BOTTOM PAD . TPD0E9096
INSTRUCTION BOOKS
RUSSIAN . TQB0E0514L
UKRAINIAN . TQB0E0514Y
I.C.s
EEPROM IC1120 X24CR26LE7A
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AENE1
A6-H2 WIRE A6-H2 TXJ/A6AGNE
A12-H1 WIRE A12-H1 TXJ/A12AGNE
DIFFERENCES FOR MODEL TX--R32LE7A
EXPLODED VIEW
A P.C.B. 16 A-R32LE7A
AC CORD ASSY 17 TXASX02AERE
AV3 BRACKET 18 TKP0E17001
BACK COVER 19 TKU0E0195
CABINET 20 TTY0E0137-2
L LCD BOTTOM MTG 21 TKZ0E9382
L LCD MTG 22 TKZ0E9380
LCD BOTTOM MTG 24 TKZ0E9412
LCD PANEL 25 L5EDD8Q00036
LCD TOP MTG 26 TKZ0E9324-1
MODEL LABEL 27 TBM0E1101
PEDESTAL ASSY 28 TTX0E0003-2
R LCD BOTTOM MTG 29 TKZ0E9383
R LCD MTG 30 TKZ0E9381
MISCELLANEOUS COMPONENTS
IR WINDOW . TKP0E17602
FELT . TMK0E090
CARTON . TPC0E72001
TOP CUSHION . TPD0E0144
BOTTOM CUSHION . TPD0E0145-1
BOTTOM PAD . TPD0E9095
INSTRUCTION BOOKS
RUSSIAN . TQB0E0514L
UKRAINIAN . TQB0E0514Y
I.C.s
EEPROM IC1120 X24CR32LE7A
TERMINALS AND LINKS
A5 - SPA5-SPK TXAJTA5AEOE1
A6-H2 WIRE A6-H2 TXJ/A6AGLE
A12-H1 WIRE A12-H1 TXJ/A12AGLE
