15.2.2. Electrical Replacement Parts List
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
PCB ETX2MM806MVH CIRCUIT BOARD P 1 (RTL)PA
VCCZ
PCB A-P50VT20E CIRCUIT BOARD A 1 (RTL)PA
VCCZ E
PCB A-P50VT20L CIRCUIT BOARD A 1 (RTL)PA
VCCZ L
PCB TXNXS1LBUE CIRCUIT BOARD XS 1 (RTL)PA
VCCZ
PCB TZTNP01LBUE CIRCUIT BOARD D 1 (RTL)PA
VCCZ
PCB TXN/K1LBUE CIRCUIT BOARD K 1 (RTL)PA
VCCZ
PCB TXN/V1LBUE CIRCUIT BOARD V 2 (RTL)PA
VCCZ
PCB TNPA5099 CIRCUIT BOARD C1 1 (RTL)
PCB TNPA5100 CIRCUIT BOARD C2 1 (RTL)
PCB TNPA5137 CIRCUIT BOARD C3 1 (RTL)
PCB TNPA5151 CIRCUIT BOARD C4 1 (RTL)
PCB TNPA5152 CIRCUIT BOARD C5 1 (RTL)
PCB TNPA5153 CIRCUIT BOARD C6 1 (RTL)
PCB TXNSC11VEK CIRCUIT BOARD SC 1 (RTL)PA
VCCZ
PCB TNPA5091AB CIRCUIT BOARD SD 1
PCB TXNSS11VEK CIRCUIT BOARD SS 1 (RTL)PA
VCCZ
PCB TNPA4804 CIRCUIT BOARD
SS2
1 (RTL)
PCB TNPA5090AB CIRCUIT BOARD SU 1
A1 K1KA11B00092 11P CONNECTOR 1
A3 K1KY15AA0719 15P CONNECTOR 1 PAVCCZ
A6 K1KA11BA0107 11P CONNECTOR 1 PAVCCZ
A7 K1KY14AA0719 14P CONNECTOR 1 PAVCCZ
A8 K1KY12AA0719 12P CONNECTOR 1
A11 K1KA04AA0728 4P CONNECTOR 1
A12 K1KA02AA0728 2P CONNECTOR 1
A20 K1KY09AA0719 9P CONNECTOR 1
A31 K1MY68BA0345 68P CONNECTOR 1
A88A K1KY30AA0369 30P CONNECTOR 1
C1009 F1G1C104A116 C 0.10UF, K, 16V 1
C1010 F1J1E105A231 C 1 UF 25V 1
C1102 F1J1A106A087 C 0.010UF, K,
10V
1
C1103 F1G1C104A116 C 0.10UF, K, 16V 1
C1104 F1G1C104A116 C 0.10UF, K, 16V 1
C1106 F1H1H270A971 C 27UF, 50V 1
C1107 F1G1H220A731 C 22UF, 50V 1
C1108 F1G1C104A116 C 0.10UF, K, 16V 1
C1109 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C1111 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C1112 F1G1C104A116 C 0.10UF, K, 16V 1
C1114 F1G1C104A116 C 0.10UF, K, 16V 1
C1117 F1G1C104A116 C 0.10UF, K, 16V 1
C1122 F1G1E103A123 C 0.010UF, K,
25V
1
C1123 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C2055 F1J1A106A087 C 0.010UF, K,
10V
1
C2057 F1J1A106A087 C 0.010UF, K,
10V
1
C2067 F1G1C103A116 C 0.010UF, K,
16V
1
C2068 F1G1C103A116 C 0.010UF, K,
16V
1
C2069 F1G1C103A116 C 0.010UF, K,
16V
1
C2070 F1G1C103A116 C 0.010UF, K,
16V
1
C2071 EEEHB0J101UR C 100PF, J, 6.3V 1
C2072 EEEHB0J101UR C 100PF, J, 6.3V 1
C2073 F1G1E333A091 C 0.033UF, K,
25V
1
C2074 F1G1E333A091 C 0.033UF, K,
25V
1
C2075 F1G1C104A116 C 0.10UF, K, 16V 1
C2076 F1G1C104A116 C 0.10UF, K, 16V 1
C2077 F1G1C104A116 C 0.10UF, K, 16V 1
C2078 F1G1A105A047 C 1UF, K, 10V 1
C2079 F1G1C103A116 C 0.010UF, K,
16V
1
C2104 F1G1H100A731 C 10PF, K, 50V 1
C2107 F1G1A105A047 C 1UF, K, 10V 1
C2108 F1G1A105A047 C 1UF, K, 10V 1
C2110 F1G1C104A116 C 0.10UF, K, 16V 1
C2301 F1G1C104A116 C 0.10UF, K, 16V 1
C2302 F1G1C104A116 C 0.10UF, K, 16V 1
C2303 F1K1E106A136 C 10UF, Z, 25V 1
C2304 F1J1E105A231 C 1 UF 25V 1
C2305 F1G1H102A730 C 1000UF, 50V 1
C2306 F1J1E105A231 C 1 UF 25V 1
C2307 F1J1E105A231 C 1 UF 25V 1
C2308 F1J1E105A231 C 1 UF 25V 1
C2311 F1K1E106A136 C 10UF, Z, 25V 1
C2313 F1G1H102A730 C 1000UF, 50V 1
C2314 F1J1E105A231 C 1 UF 25V 1
C2315 F1K1E106A136 C 10UF, Z, 25V 1
C2316 F1H1H104A970 C 0.1UF, K, 50V 1
C2317 F1J1E105A231 C 1 UF 25V 1
C2318 F1H1H104A970 C 0.1UF, K, 50V 1
C2319 F1K1E106A136 C 10UF, Z, 25V 1
C2320 F1J1E105A231 C 1 UF 25V 1
C2321 F1H1H104A970 C 0.1UF, K, 50V 1
C2322 F1K1E106A136 C 10UF, Z, 25V 1
C2323 F1H1H104A970 C 0.1UF, K, 50V 1
C2324 F1J1E105A231 C 1 UF 25V 1
C2325 F1G1H102A730 C 1000UF, 50V 1
C2334 F1J1H474A757 C 0.47UF, 50V 1
C2335 F1H1E104A129 C 0.1UF, 25V 1
C2336 F1H1E104A129 C 0.1UF, 25V 1
C2337 F1J1H474A757 C 0.47UF, 50V 1
C2338 F1H1E104A129 C 0.1UF, 25V 1
C2339 F1H1E104A129 C 0.1UF, 25V 1
C2340 F1H1H223A970 C 0.22UF, K, 50V 1
C2341 F1H1H223A970 C 0.22UF, K, 50V 1
C2342 F1H1H223A970 C 0.22UF, K, 50V 1
C2343 F1H1H223A970 C 0.22UF, K, 50V 1
C2344 F1H1H223A970 C 0.22UF, K, 50V 1
C2345 F1H1H223A970 C 0.22UF, K, 50V 1
C2346 F1H1H223A970 C 0.22UF, K, 50V 1
C2347 F1H1H223A970 C 0.22UF, K, 50V 1
C2349 F1G1H102A730 C 1000UF, 50V 1
C2351 F1G1H102A730 C 1000UF, 50V 1
C2353 F1G1H102A730 C 1000UF, 50V 1
C2355 F1G1H102A730 C 1000UF, 50V 1
C2411 F1K1E106A136 C 10UF, Z, 25V 1
C2413 F1G1H102A730 C 1000UF, 50V 1
C2414 F1J1E105A231 C 1 UF 25V 1
C2415 F1K1E106A136 C 10UF, Z, 25V 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
