Panasonic TX-P50VT50E - Parts List

Model No. : TX-P50VT50E/J/T Parts List
Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
PCB A-P50VT50E CIRCUIT BOARD A 1 (E) (RTL)PAVCCZ
PCB A-P50VT50J CIRCUIT BOARD A 1 (J) (RTL)PAVCCZ
PCB A-P50VT50T CIRCUIT BOARD A 1 (T) (RTL)PAVCCZ
PCB TXN/K1SUUE CIRCUIT BOARD K 1 (RTL)PAVCCZ
PCB N0AE6KL00010 CIRCUIT BOARD P 1 PAVCCZ
PCB TXNC11RFUU CIRCUIT BOARD C1 1 (RTL)PAVCCZ
PCB TXNC21RFUU CIRCUIT BOARD C2 1 (RTL)PAVCCZ
PCB TXNC31RFUU CIRCUIT BOARD C3 1 (RTL)PAVCCZ
PCB TXNSC1SRUJ CIRCUIT BOARD SC 1 (RTL)PAVCCZ
PCB TXNSD1RFUU CIRCUIT BOARD SD 1 PAVCCZ
PCB TXNSS1RBUU CIRCUIT BOARD SS 1 (RTL)PAVCCZ
PCB TXNSS21RFUU CIRCUIT BOARD SS2 1 (RTL)PAVCCZ
PCB TXNSU1RFUU CIRCUIT BOARD SU 1 PAVCCZ
A1 K1KA08B00270 8P CONNECTOR 1
A6 K1KY16BA0394 16P CONNECTOR 1 PAVCCZ
A8 K1KY06AA0719 6P CONNECTOR 1
A12 K1KY06BA0387 6P CONNECTOR 1 PAVCCZ
A20 K1MY30BA0345 30P CONNECTOR 1
A31 K1MY55BA0345 55P CONNECTOR 1
A32 K1MY55BA0345 55P CONNECTOR 1
A33 K1MN20BA0231 20P CONNECTOR 1
A50 K1KY05AA0719 5P CONNECTOR 1
C0902 F1G1H101A834 C 100PF 50V 1 PAVCCZ
C0903 F1G1H101A834 C 100PF 50V 1 PAVCCZ
C2000 F1G1E1030005 C 0.01UF 25V 1
C2001 F1J1A106A110 C 10UF, 10V 1 PAVCCZ
C2002 F1J1E105A287 C 1UF, 25V 1 PAVCCZ
C2003 F1J1E105A287 C 1UF, 25V 1 PAVCCZ
C2006 F1G1C104A077 C 0.1UF 16V 1
C2007 F1G1A105A047 C 1UF 10V 1
C2008 F1G1A105A047 C 1UF 10V 1
C2009 F1G1E1030005 C 0.01UF 25V 1
C2010 F1G1A105A047 C 1UF 10V 1
C2013 F1G1E1030005 C 0.01UF 25V 1
C2014 F1G1E1030005 C 0.01UF 25V 1
C2018 F1G1H1020008 C 1000PF 50V 1
C2019 F1G1E1030005 C 0.01UF 25V 1
C2026 F1G1C104A077 C 0.1UF 16V 1
C2032 F1H0J4750004 C 4.7UF, 16V 1
C2035 F1J1A106A087 C 10UF, 10V 1
C2036 F1J1A106A087 C 10UF, 10V 1
C2810 F1H1H103B047 C 0.01UF, 50V 1 PAVCCZ
C2811 F1J1A106A087 C 10UF, 10V 1
C2815 F1H1H103B047 C 0.01UF, 50V 1 PAVCCZ
C2821 ECJ1XB1C104K C 0.1UF, Z, 16V 1
C3001 F1G1A105A047 C 1UF 10V 1
C3002 F1G1A105A047 C 1UF 10V 1
C3003 F1G1C104A077 C 0.1UF 16V 1
C3004 F1G1C104A077 C 0.1UF 16V 1
C3005 F1G1A105A047 C 1UF 10V 1
C3006 F1G1A105A047 C 1UF 10V 1
C3007 F1J1A106A110 C 10UF, 10V 1 PAVCCZ
C3008 F1J1A106A110 C 10UF, 10V 1 PAVCCZ
C3009 F1J1A106A110 C 10UF, 10V 1 PAVCCZ
C3011 F1J1A106A110 C 10UF, 10V 1 PAVCCZ
C3016 F1G1C104A077 C 0.1UF 16V 1
C3018 F1G1C104A077 C 0.1UF 16V 1
C3019 F1G1C104A077 C 0.1UF 16V 1
C3020 F1J1A106A110 C 10UF, 10V 1 PAVCCZ
C3036 F1G1A105A047 C 1UF 10V 1
S-37
