Page #22 background imageLoading...
Page #22 background image
2-7. Room Unit (Main Monitor) : VL-MVN511 Rea Side
Role/ Features / Installation
2
Commercially Sensor or Button
(Support Emergency call)
Commercially Sensor or Button
(Support Door Bell)
D3,D4 :
Door Station
D1,D2 :
Distribution Box(VL-V701)
21
