Panasonic VL-SVN511AZ Installation Guide

2-4. Distribution Box & Repeater : VL-V701
2
Role/ Features / Installation
AC
Distribution Box
Room unit (up to 20)
Main Monitor Door Station
#19
MVN511
MW251
#20
DB1
DB2
MV26
Termination:ON
Repeater:OFF
Control Box
Lobby Station
Category Meaning
POWER
(GREEN)
ACCESS
(RED)
Normal operation Idle Lit Off
Call or monitoring in progress Lit Lit
Error
DIP switch 8 is in the "on" position Off Flashing slowly
Two or more DIP switches are in
the "on" position
Off Flashing slowly
Role of the VL-V701
14

Panasonic VL-SVN511AZ Specifications

General

Brand	Panasonic
Model	VL-SVN511AZ
Category	Intercom System
Language	English
