4-2. Connecting to analogue security cameras & Monitor Uses
4
Integration
・ 1 camera can be connected to each lobby station.
・ 1 Monitor can be connected to Control Box
Lobby
48
Gym/Pool（CCTV)
Security(Monitor)
Gate（CCTV)
