Panasonic VL-SVN511AZ Installation Guide

5-2-1. How to Setup
5
Setup Tool
1. Change to the new Room Monitor
If you do not use Setup tool, you can programing
from new Room Monitor.
<Situation3> If you change one room monitor in the existing system.
2. On the PC setup tool
select the back up date folder
and then select the existing files.
No. 301
Control Box
VL-V700
Distribution Box
VL-V701
3. Connect the PC and Control Box vis USB and
send(set) the General date to the new Monitor
No. 301
Port?
Port?
Control Box
VL-V700
Distribution Box
VL-V701
No. 301
Port?
Port?
Control Box
VL-V700
Distribution Box
VL-V701
301
60
