Lobby Station － Control Box : New Cable (Cat-6)
Control Box － Distribution Box : New Cable (Cat-6)
Distribution Box － Room Monitor : Exiting Cable(PVC cable less than 30m)
Replace from Intercom system (PVC mesh cable)
Distribution Box
VL-V701
Control Box
VL-V700
Cat6 Cable
Replace
77
