Panasonic WH-SXC09F9E8

140
17.3 To Remove Pressure Gauge
Pressure Gauge
1. Remove 3 screws then use
spanner to release nut of
Pressure Gauge.
17.4 To Remove Control Panel
Control Panel
1. Disconnect the connector
Electronic Controller Board
from the Electronic Controlle
r
of CN-REMOTE2 (WHT)
Board.
2
. Remove 5 screws to remove
Control Panel.
