Panasonic WH-SXC09F9E8

155
<Model: WH-SXC09F3E8 WH-SXC09F9E8 WH-SXC12F9E8>
SAFETY
REF.
NO.
DESCRIPTION & NAME QTY. WH-SXC09F3E8 WH-SXC09F9E8 WH-SXC12F9E8 REMARK
1 BASE PAN 1 CWD521279 ← ←
2
HOT WATER COIL -
COMPLETE
1 CWB90C1109 ← ←
3 RECEIVER 1 CWB141039 ← ←
4 FLOW SWITCH VALVE 1 CWB621128 ← ←
6 FLARE NUT (5/8) 1 CWT251061 ← ←
7 FLARE NUT (7/8) 1 CWT251064 ← ←
9 WATER PUMP 1 CWB532116 ← ←
10 PACKING (O-RING) I.D 32mm 1 CWB811082 ← ←
13 PRESSURE RELIEF VALVE 1 CWB621092 ← ←
14 RETAINING RING D:22mm 1 CWH581007 ← ←
15 CLIP SENSOR 4 CWH32138 ← ←
16 BOTTLE COMPLETE 1 CWH90C0044 CWH90C0045 ←
17 HEATER ASS'Y 1 CWA34K1042 CWA34K1030 ←
18 SOUND PROOF MATERIAL 1 CWG302835 CWG302853 ←
19 THERMOSTAT 4 CWA151074 ← ← O
20
ELECTRONIC CONTROLLER -
MAIN
1 CWA73C8147 CWA73C8148 CWA73C8151 O
21
TERMINAL BOARD ASS'Y
(TO OUTDOOR)
1 CWA28K1240 ← ← O
22
TERMINAL BOARD ASS'Y
(HEATER)
1 CWA28K1236 ← ← O
25
TERMINAL BOARD ASS'Y
(TO 2,3 WAY VALVE)
1 CWA28K1229 ← ← O
26
TERMINAL BOARD ASS'Y
(TO BOOSTER HEATER &
ROOM THERMOSTAT)
1 CWA28K1230 ← ← O
28
TERMINAL BOARD ASS'Y
(TO TANK)
1 CWA28K1231 ← ← O
29
RESIDUAL CURRENT
CIRCUIT BREAKER
1/2 CWA181008 ← ← O
29a
RESIDUAL CURRENT
CIRCUIT BREAKER
1 K5KYYAY00003 - ← O
30 TRANSFORMER - COMPLETE 1 CWA40C1096 ← ← O
31
SENSOR - COMPLETE
(CN-TH1)
1 CWA50C2762 ← ← O
31a
SENSOR - COMPLETE
(CN-TH3)
1 CWA50C3164 ← ← O
32
REMOTE CONTROL
COMPLETE
1 CWA75C4464 ← ← O
33 PRESSURE GAUGE 1 CWB070001 ← ←
33a FLARE NUT (1/4) 1 CWT251063 ← ←
34 AIR PURGE VALVE 1 CWB621094 ← ←
35 CABINET 1 CWE001050A ← ←
36 HANDLE 2 CWE161008 ← ←
37 CABINET FRONT PLATE 1 CWE061265A ← ←
38 INSTALLING HOLDER 1 CWH361103A ← ←
38a INSTALLING HOLDER 1 CWH361119A ← ←
39 OPERATING INSTRUCTION 1 CWF569597 ← ←
39a OPERATING INSTRUCTION 1 CWF569598 ← ←
40 INSTALLATION INSTRUCTION 1 CWF615946 ← ←
41
ACCESSORY - COMPLETE
(L-TUBE)
1 CWH82C1763 ← ←
42 ACCESSORY - COMPLETE 1 CWH82C1754 ← ←
43 CONTROL BOARD 1 CWH102409 ← ←
44 CONNECTING BAR 2 CWE261147 ← ←
45 PACKING 2 CWB811190 ← ←
46 REACTOR 1 G0C103Z00003 ← ← O
47 TERMINAL COVER (HEATER) 1 CWH171052 ← ←
48
TERMINAL COVER
(THERMOSTAT)
1 CWH171051 ← ←
49 BAG 1 CWG861447 ← ←
