Panasonic WH-SXC09F9E8

160
<Model: WH-UX09FE8 WH-UX12FE8>
SAFETY REF. NO. DESCRIPTION & NAME QTY. WH-UX09FE8 WH-UX12FE8 REMARK
1 BASE PAN ASS’Y 1 CWD52K1275 ←
2 COMPRESSOR 1 5JD420XBA22 ← O
3 BUSHING - COMPRESSOR MOUNT 3 CWH50055 ←
4 NUT - COMPRESSOR MOUNT 3 CWH561049 ←
4a GASKET FOR TERMINAL COVER 3 CWB811017 ←
5 CRANKCASE HEATER 1 CWA341053 ←
6 CONDENSER COMPLETE 1 CWB32C3986 ←
7 HIGH PRESSURE SENSOR 1 CWA501463 ← O
8 DISCHARGE MUFFLER 1 CWB121014 ←
9 PRESSURE SWITCH 1 CWA101007 ←
10 3-WAYS VALVE (GAS) 1 CWB011251 ← O
11 4-WAYS VALVE 1 CWB001046 ← O
12 3-WAYS VALVE 1 CWB011292 ← O
13 STRAINER 2 CWB111032 ←
14 STRAINER 1 CWB111032 ←
15 TERMINAL COVER 1 CWH171039A ←
16 NUT - TERMINAL COVER 1 CWH7080300J ←
19 ACCUMULATOR 1 CWB131026A ←
20 SOUND PROOF MATERIAL 1 CWG302881 ←
21 SOUND PROOF MATERIAL 1 CWG302266 ←
22 SOUND PROOF BOARD 1 CWH15K1031 ←
23 V-COIL COMPLETE (4 WAY VALVE) 1 CWA43C2169J ← O
24
V-COIL COMPLETE (MAIN EXPANSION
VALVE)
1 CWA43C2602 ← O
25 SENSOR -COMP. - OUTLET TEMP (TH1) 1 CWA50C2730 ← O
26
SENSOR - COMP. - DISCHARGE TEMP
(CN-DIS)
1 CWA50C2576 ← O
27 SENSOR -COMP. - COMP TANK (CN-TANK) 1 CWA50C2629 ← O
27a SENSOR - COMP. - DEFROST TEMP (TH2) 1 CWA50C2577 ← O
28 CABINET REAR PLATE - COMPLETE 1 CWE02C1064 ←
29 CONTROL BOARD CASING 1 CWH10K1049 ←
31 TERMINAL BOARD ASS’Y 1 CWA28K1214 ← O
38 ELECTRONIC CONTROLLER - NF 1 CWA747838 ← O
44 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C7983R CWA73C8146R O
46 REACTOR (P1) 3 G0C293J00001 ← O
47 REACTOR (P2) 3 G0C153J00009 ← O
50 FAN MOTOR BRACKET 1 CWD54K1084 ←
50a SCREW-FAN MOTOR BRACKET 8 CWH551040J ←
53 FAN MOTOR (UPPER) 1 EHDS83CAC ← O
54 FAN MOTOR (LOWER) 1 EHDS83DAC ← O
54a SCREW - FAN MOTOR MOUNT 8 CWH551323 ←
55 PROPELLER FAN ASSY 2 CWH00K1006 ←
56 NUT 2 CWH561092 ←
57 CABINET FRONT PLATE 1 CWE061098A ←
58 DISCHARGE GRILLE 2 CWE201073 ←
59 CABINET SIDE PLATE ASSY 1 CWE04K1023A ←
60 WIRE NET 1 CWD041103A ←
61 CABINET TOP PLATE CO. 1 CWE03C1096 ←
62 HANDLE 2 CWE161008 ←
64 PIPE COVER (FRONT) 1 CWD601074A ←
65 PIPE COVER (BACK) 1 CWD601075A ←
66 CABINET FRONT PLATE CO. 1 CWE06C1091 ←
68 TUBE ASSY (CAP.TUBE) 1 CWT07K1606 ←
69 ACCESSORY CO.(DRAIN ELBOW) 1 CWG87C2030 ←
70 EXPANSION VALVE (1) 1 CWB051049 ← O
