4
Resolution
Barcode type
Wide-narrow
element ratio
Barcode content
Contrast
3 mil
Code39
2.5：1
123
80%
4 mil
Code39
2.5：1
123456789
80%
5 mil
Code39
2.5：1
123
80%
10 mil
Code39
2.5：1
123
80%
13 mil
100%UPC
-
123456
80%
15 mil
Code39
2.5：1
1
80%
20 mil
Code39
2.5：1
1
80%
30 mil
Code39
2.5：1
EF
80%
2 Get started
2-1 Electrical interface/Pin assignment
The scanner provides a RJ-45 cable connector.
Table 2-1 lists the pin assignments of the scanner.
Figure 2-1 Electrical interface/Pin
Pin 10
Pin 1
Cable connector
